The Elkay EZH2O® Bottle Filling Station delivers a clean quick water bottle fill and enhances sustainability by minimizing dependency on disposable plastic bottles. Vandal-resistant cooler and bottle filling station in a consolidated space saving ADA compliant design. Pushbutton activation of bubbler with automatic 20-second shut-off timer on bottle filler.
Elkay VRCGRN8WSK Features:
Touchless sensor activation (bottle filler) and vandal-resistant push-button activation for the water cooler designed for easy use
High-performance compressor and insulation greatly reduce energy consumption
Fill rate is 1.1 GPM
Green Ticker™ informs user of number of 20 oz plastic water bottles saved from waste
Laminar flow provides clean fill with minimal splash
Silver ion antimicrobial protection on key plastic components to inhibit the growth of mold and mildew
Vandal-resistant, StreamSaver bubblers feature chrome-plated integral hood guard to prevent contamination, tampering and reduce water usage
Rated for indoor use
Elkay VRCGRN8WSK Technologies and Benefits:
Ease of Installation: TheezH20 are designed to be installed without any trouble. One connection is all you need to get operational and everything comes in one box.
Smart System: With new diagnostics, managers can monitor all stations and track savings across your facility.
Graphic Display: Graphic display shows water bottle count and provides user assistance to make maintenance easier.
Elkay VRCGRN8WSK Specifications:
Height: 39-3/4″ (measured from lowest rim to top rim of fixture)
Length: 18-1/16″ (measured from most left to most right rim of fixture)
Depth: 18-5/8″ (measured from back to front of fixture)
Installation Type: Wall Mounted
Fountain Type: Cooler
Hands Free Bottle Filler Operation: Yes
Bottle Filler Flow Rate(GPM): 1.1
Fountain Flow Rate(GPM): 0.13
Voltage: 115V/60Hz
Number of Stations: 1
ADA Compliant: Yes
Vandal Resistant Bubbler: Yes
Filtered: No
Additional Elkay Links
View the Manufacturer Warranty
Browse all Elkay Products
Elkay EZH2O Collection
Specifications
| Height | 39.75 in. |
| Product Weight | 89 lbs. |
| Width | 18.625 in. |
| Flow Rate (GPM) | 0.13, 1.1 |
| Length | 18.06 in. |
| Water Pressure (Max) | 105 PSI |
| Water Pressure (Min) | 20 PSI |
| Cooling Capacity | 8 GPH |
| Inside Diameter | 0.375 in. |
| Outside Diameter | 1.25 in. |
| Insulation Type | Wall Mounted |
| Material | ABS, Stainless Steel |
| Thermostat | Modern |
| Energy Efficient | Yes |
| Control Type | Push Button |
| Vandal Resistant | Yes |
| Antimicrobial | Yes |
| Bi-Level | No |
| Filtered | No |
| Freeze Resistant | No |
| Hands Free | Yes |
| Number of Stations | 1 |
| Pet Friendly | No |
| Approved for Commercial Use | Yes |
| Collection | EZH2O |
| Made in America | Yes |
| Manufacturer Warranty | 5 Year Limited |
| ADA | Yes |
| Certifications | NSF, ANSI, ASME, UL, CSA |
| Lead Leaching Certified NSF/ANSI 61 | Yes |
| Location Rating | Dry Location |
| Outdoor Approved | No |
| ASSE Code | A112.19.3 |
| Voltage | 115 |
| Wattage | 260 |
| Amperage | 3.8 |
| Frequency | 60 Hertz |
| Electrical Phases | 1 |
| Bottle Filler Included | Yes |
| Cooling Unit | Yes |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
