Single Cylinder Keyed Entry: Single cylinder keyed entry door hardware is locked and unlocked from the exterior using a key and can be locked and unlocked from the interior using the locking mechanism. Perfect for securing entrances, side doors, and anywhere else that needs a bit more security.
Features:
Tested to exceed ANSI/BHMA Grade 2 security requirements
Covered by Kwikset’s limited lifetime finish and limited lifetime mechanical manufacturer warranties
Interior lever is ADA compliant
Fully reversible lever, can be installed on both right handed and left handed doors in minutes with just a screwdriver
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 1-3/4″
Handing: Reversible Left or Right
Cylinder: SmartKey 5 Pin KW1
Latch Faceplate: Round Corner or Square Corner
Handle Length: 4-1/4″
Handle Projection: 2-1/4″
Trim Height: 2-11/16″
Trim Width: 2-11/16″
Additional Kwikset Links
View the Manufacturer Warranty
Browse all Kwikset Products
Kwikset Singapore Collection
Specifications
| Thermostat | Contemporary |
| Cylinder | SmartKey 5 Pin |
| Cylinder Type | Single Cylinder |
| Function | Keyed Entry, Entrance |
| Handshower | Left, Reversible, Right |
| Handle Style | Lever |
| Keyway | KW1 |
| Latch Faceplate | Round Corner, Square Corner |
| Concealed Screws | No |
| Handle Material | Metal |
| Rosette Shape | Square |
| Interconnected | No |
| Panic Proof | No |
| Lever Shape | Flat, Square, Straight |
| Collection | Singapore |
| Country Of Origin | Taiwan |
| Manufacturer Warranty | Limited Lifetime Finish, Limited Lifetime Mechanical |
| BHMA Certification | Grade 2 |
| Series | Contemporary |
| ADA | No |
| Fire Rated | No |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Edge Bore | 1" |
| Handle Projection | 2.25 in. |
| Trim Height | 2.6875 in. |
| Product Weight | 2.25 lbs. |
| Trim Width | 2.6875 in. |
| Handle Length | 4.21875 in. |
| Cylinder Included | Yes |
| Interchangeable Core | No |
| Color | Matte Black |
