Product Features:
Valve is constructed of brass ensuring durability and dependability
Covered under Moen’s limited lifetime warranty for residential installations and 5-year limited warranty for commercial installations
Features Moen’s M-PACT® common valve system
Designed for IPS inlet / outlet connections
Designed to provide the exact amount of water you need
Operates counterclockwise through a 90° arc
Connection Size: 3/4″
Connection Type: IPS
Sturdy mounting bracket included with valve
Note: This is the rough-in valve only – valve trim is required to complete product
Product Technologies / Benefits:
M-PACT® Common Valve System: This innovation from Moen gives the homeowner the up-most functionality and convenience when it comes to bathroom faucets. Designed to be a catch-all valve system, once M-PACT® is installed you can upgrade the style of the lavatory or shower faucet without replacing nay of the faucet plumbing.
Different Types of Valve Inlet / Outlet Connections:
Additional Moen Links
View the Manufacturer Warranty
Browse all Moen Products
Moen M-Pact Collection
Specifications
| Thermostat | Modern |
| Material | Brass |
| Valve Type | Ceramic Disc |
| Water Connection Type | IPS |
| Configuration | Volume Control Valve |
| Valve Function | Volume Control |
| Scald Guard | No |
| Digital | No |
| Installation Hardware Included | Yes |
| Volume Control | Yes |
| Cartridge Included | Yes |
| Trim Included | No |
| Approved for Commercial Use | Yes |
| Manufacturer Warranty | 5 Year Limited Commercial, Limited Lifetime Residential |
| ASSE Code | A112.18.1 |
| Certifications | CSA, ASME |
| CSA Code | B125.1 |
| Max Deck Thickness | 2.25 in. |
| Water Connection | 3/4" |
| Inside Diameter | .75 in. |
| Outside Diameter | .75 in. |
