Coordinating Complete Toilets:
270CB001 – Complete toilet with left-hand tank lever and 10″ rough-in
270CA001 – Complete toilet with left-hand tank lever and 12″ rough-in
Product Features:
Replacement for 3014.001 (Specs/dimensions are the same)
Fully covered under a 5 year warranty – 5 times the industry standard
Quick, quiet flushing – American Standard toilets are famously efficient and hushed
Industry-leading flushing system out-performs older toilets while using less than half the water
EverClean porcelain surface is extremely easy to keep clean, including inside the bowl
Sanitary bar on bowl prevents liquids from traveling under the tank
Elongated bowl shape – more comfortable than a round bowl
Shorter-height bowl – appropriate for children and smaller adults
Straight-forward installation instructions are included with each toilet
100% factory flush tested – guaranteed to perform
Cadet 3 Flushing:
3″ Flush Valve – The flush starts with a flushing system that employs a 3″ valve opening, allowing water to enter the bowl at a much faster rate than the industry standard 2″ flush valve. Controlled by a flapper that is engineered to be chemical-resistant, the Cadet flushing valve system is highly regarded for its durability.
360 Degree Cleaning –Â Water entering the bowl does so in a sweeping 360-degree motion. This is designed to help completely clear the bowl, even while using less water.
Powerful Siphoning Water Jet – A perfectly positioned water jet captures the circular flow of water for optimal performance with minimal energy loss (water doesn’t hit a flat spot and slow down). As waste and water exit, they are siphoned into the trapway for an unmatched push/pull one-two punch.
2-1/8″ Fully Glazed Trapway – Waste and water exit the toilet through a trapway that is fully glazed, which seals it and provides for a smooth surface that waste can in no way cling to. The 2-1/8″ diameter chute, while slightly narrower than the American Standard Champion flushing system’s 2-3/8″ trapway, can still flush up to 150 feet of toilet paper without clogging. Not that you’ll ever use that much.
Other Technologies / Benefits:
EverClean Surface – Using the antimicrobial properties of silver (the precious metal), EverClean Surfaces inhibit the growth of bacteria, mold, and mildew. The super smooth, baked-in, mirror-like surface not only eliminates unsightly rings, but also helps repel toilet messes.
Product Specifications:
Bowl Height: 15″ (bottom of the base to the rim)
Flush Valve Size: 3″ (diameter of the inlet for water entering bowl from tank)
Trapway Size: 2-1/8″ (diameter of the outlet for water/waste exiting the bowl)
Water Area: 9″ X 8″ (inner rim dimensions length X width)
Water Depth (From Rim): 7″
Rough In: 10″ or 12″ rough-in dependent on tank (wall behind toilet to center of waste outlet hole in floor)
Why Buy American Standard From Us:
We are an American Standard Preferred Authorized Online Dealer
We Only Ship Showroom Quality products vs Builder Grade quality found at big box retailers
All metal parts, not plastic like some of our competitors
Customer Care Experts Available 7 Days a Week to Serve You Before & After Purchase
A Showroom Experience from the Comfort of Your Home or Office
Â
Additional American Standard Links
View the Manufacturer Warranty
Browse all American Standard Products
American Standard Cadet 3 Collection
Specifications
| Height | 15 in. |
| Product Weight | 50 lbs. |
| Width | 14 in. |
| Depth | 28.5 in. |
| Length (Inside) | 9 in. |
| Width (Inside) | 8 in. |
| Bowl Height | 15 in. |
| Flush Valve Size | 3 in. |
| Rough In | 10, 12 in. |
| Trapway | 2.125 in. |
| Water Area | 9 x 8 |
| Material | Vitreous China |
| Thermostat | Modern |
| Insulation Type | Floor Mounted |
| Water Efficient | Yes |
| Configuration | Bowl Only |
| Bowl Shape | Elongated |
| Design Features | Glazed Trapway |
| Seat Front | Closed |
| Flush Type | Siphon Jet |
| Branded Surface Treatment | EverClean |
| ADA | No |
| Approved for Commercial Use | No |
| Country Of Origin | USA |
| Manufacturer Warranty | 5 Year Limited |
| Collection | Cadet 3 |
| Series | Cadet |
| Certifications | ASME, CSA |
| Eco Friendly | Yes |
| ASSE Code | A112.19.2 |
| CSA Code | B45.1 |
| Seat Included | No |
| Color | Black, Bone, Linen, White |
| Color Tone | Blacks, Neutrals, Whites |
