American Standard 20DB.8332283C Features:
Made of 20 gauge stainless steel
Drop-in installation
Double basin sink with a 50/50 split
Sound absorbing pads prevents dish clatter and undercabinet condensation
Colony Pro Stainless Steel faucet with single lever handle and deck plate included
Includes two drain fittings with strainer
Installation hardware and cut out template included
American Standard 20DB.8332283C Sink Specifications:
Length: 32-15/16″ (left to right of the sink)
Width: 21-15/16″ (front to back of the sink)
Height: 8″ (top to bottom of the sink)
Right Basin Dimensions:
Length: 14″ (left to right)
Width: 15-15/16″ (front to back)
Height: 8″ (top to bottom)
Left Basin Dimensions:
Length: 14″ (left to right)
Width: 15-15/16″ (front to back)
Height: 8″ (top to bottom)
Drain Location: Center
Drain Connection Size: 3-9/16″
Faucet Hole Size: 1-1/2″
Number of Faucet Holes: 3
Minimum Cabinet Size: 36″ (minimum left to right cabinet dimension)
American Standard 20DB.8332283C Faucet Specifications:
Overall Height: 6-1/2″ (counter top to highest point of faucet)
Spout Height: 4-9/10″ (counter top to water outlet)
Spout Reach: 8-1/2″ (center of faucet base to center of water outlet)
Flow Rate: 1.5 gallons-per-minute
Faucet Centers: 8″ (distance between handle installation holes)
Faucet Holes: 3 (number of holes required)
Maximum Deck Thickness: 1″
Escutcheon Width: 10-3/8″
Why Buy American Standard From Us:
We are an American Standard Preferred Authorized Online Dealer
We Only Ship Showroom Quality products vs Builder Grade quality found at big box retailers
All metal parts, not plastic like some of our competitors
Customer Care Experts Available 7 Days a Week to Serve You Before & After Purchase
A Showroom Experience from the Comfort of Your Home or Office
Â
Additional American Standard Links
View the Manufacturer Warranty
Browse all American Standard Products
American Standard Colony Collection
Specifications
| Installation Hardware Included | Yes |
| Drain Assembly Included | Yes |
| Escutcheon Included | Yes |
| Handshower Included | Yes |
| Sidespray | No |
| Basin Rack Included | No |
| Basket Strainer Included | No |
| Colander Included | No |
| Cutting Board Included | No |
| Faucet Included | Yes |
| Insulation Type | Drop In |
| Material | Stainless Steel |
| Thermostat | Traditional |
| Faucet Holes | 3 |
| Faucet Type | Kitchen Faucet |
| Handle Material | Metal |
| Handle Style | Lever |
| Number Of Handles | 1 |
| Pullout Spray | No |
| Spout Type | Swivel |
| Drain Placement | Center |
| Basin Split | 50/50 |
| Farmhouse | No |
| Number Of Bathers | 2 |
| Sink Shape | Rectangular |
| Sound Dampening | Yes |
| Overflow | No |
| Apron Front | No |
| Sink Material | Stainless Steel |
| Faucet Material | Brass |
| Undercoating | Yes |
| Manufacturer Warranty | Limited Lifetime |
| Certifications | NSF, ASME, CSA |
| ADA | No |
| CA Drought Compliant | Yes |
| Low Lead Compliant | Yes |
| ASSE Code | A112.18.1, A112.19.3 |
| CSA Code | B125.1 |
| Width | 21.938 in. |
| Faucet Centers | 8 in. |
| Flow Rate (GPM) | 1.5 |
| Max Deck Thickness | 1 in. |
| Spout Height | 4.9 in. |
| Spout Reach | 8.5 in. |
| Spout Swivel | 360 Degrees |
| Water Connection | 1/2" |
| Length | 32.938 in. |
| Nominal Width | 22 in. |
| Nominal Length | 33 in. |
| Faucet Hole Size | 1.5 in. |
| Backplate Depth | 8 in. |
| Drain Connection | 3.563 in. |
| Minimum Cabinet Size | 36 in. |
| Sink Length | 32.938 in. |
| Escutcheon Width | 10.375 in. |
| Gauge | 20 |
| Handle Height | 6.5 in. |
| Faucet Height | 6.5 in. |
| Sink Height | 8 in. |
| Sink Width | 21.938 in. |
| Basin Depth (Left) | 8 in. |
| Basin Depth (Right) | 8 in. |
| Basin Length (Left) | 14 in. |
| Basin Length (Right) | 14 in. |
| Basin Width (Left) | 15.938 in. |
| Basin Width (Right) | 15.938 in. |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
