American Standard 20DB.8332284S Features:
Made of 20 gauge stainless steel
Drop-in installation
Double basin sink with a 50/50 split
Sound absorbing pads prevents dish clatter and undercabinet condensation
Includes two drain fittings with strainer
Installation hardware and cut out template included
American Standard 20DB.8332284S Specifications:
Length: 32-15/16″ (left to right of the sink)
Width: 21-15/16″ (front to back of the sink)
Height: 8″ (top to bottom of the sink)
Right Basin Dimensions:
Length: 14″ (left to right)
Width: 15-15/16″ (front to back)
Height: 8″ (top to bottom)
Left Basin Dimensions:
Length: 14″ (left to right)
Width: 15-15/16″ (front to back)
Height: 8″ (top to bottom)
Drain Location: Center
Drain Connection Size: 3-9/16″
Faucet Hole Size: 1-1/2″
Number of Faucet Holes: 4
Minimum Cabinet Size: 36″ (minimum left to right cabinet dimension)
Why Buy American Standard From Us:
We are an American Standard Preferred Authorized Online Dealer
We Only Ship Showroom Quality products vs Builder Grade quality found at big box retailers
All metal parts, not plastic like some of our competitors
Customer Care Experts Available 7 Days a Week to Serve You Before & After Purchase
A Showroom Experience from the Comfort of Your Home or Office
Additional American Standard Links
View the Manufacturer Warranty
Browse all American Standard Products
American Standard Colony Collection
Specifications
| Width | 21.938 in. |
| Height | 8 in. |
| Length | 32.938 in. |
| Nominal Length | 33 in. |
| Backplate Depth | 8 in. |
| Drain Connection | 3.563 in. |
| Faucet Centers | 8 in. |
| Nominal Width | 22 in. |
| Faucet Hole Size | 1.5 in. |
| Gauge | 20 |
| Sink Length | 32.938 in. |
| Minimum Cabinet Size | 36 in. |
| Basin Depth (Left) | 8 in. |
| Basin Depth (Right) | 8 in. |
| Basin Length (Left) | 14 in. |
| Basin Length (Right) | 14 in. |
| Basin Width (Left) | 15.938 in. |
| Basin Width (Right) | 15.938 in. |
| Thermostat | Traditional |
| Material | Stainless Steel |
| Insulation Type | Drop In |
| Drain Placement | Center |
| Faucet Holes | 4 |
| Overflow | No |
| Sink Shape | Rectangular |
| Number Of Bathers | 2 |
| Farmhouse | No |
| Sound Dampening | Yes |
| Basin Split | 50/50 |
| Apron Front | No |
| Undercoating | Yes |
| Installation Hardware Included | Yes |
| Faucet Included | No |
| Basin Rack Included | No |
| Basket Strainer Included | No |
| Colander Included | No |
| Cutting Board Included | No |
| Manufacturer Warranty | Limited Lifetime |
| Certifications | ASME |
| ADA | No |
| ASSE Code | A112.19.3 |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
