American Standard 22DB.6332283C Features:
Made of 20 gauge stainless steel
Drop-in installation
Double basin sink with a 50/50 split
Sound absorbing pads prevents dish clatter and undercabinet condensation
Colony Pro Stainless Steel faucet with single lever handle and deck plate included
Includes two drain fittings with strainer
Installation hardware and cut out template included
American Standard 22DB.6332283C Sink Specifications:
Length: 32-15/16″ (left to right of the sink)
Width: 21-15/16″ (front to back of the sink)
Height: 6″ (top to bottom of the sink)
Right Basin Dimensions:
Length: 14″ (left to right)
Width: 15-15/16″ (front to back)
Height: 6″ (top to bottom)
Left Basin Dimensions:
Length: 14″ (left to right)
Width: 15-15/16″ (front to back)
Height: 6″ (top to bottom)
Drain Location: Center
Drain Connection Size: 3-9/16″
Faucet Hole Size: 1-1/2″
Number of Faucet Holes: 3
Minimum Cabinet Size: 36″ (minimum left to right cabinet dimension)
American Standard 22DB.6332283C Faucet Specifications:
Overall Height: 6-1/2″ (counter top to highest point of faucet)
Spout Height: 4-9/10″ (counter top to water outlet)
Spout Reach: 8-1/2″ (center of faucet base to center of water outlet)
Flow Rate: 1.5 gallons-per-minute
Faucet Centers: 8″ (distance between handle installation holes)
Faucet Holes: 3 (number of holes required)
Maximum Deck Thickness: 1″
Escutcheon Width: 10-3/8″
Why Buy American Standard From Us:
We are an American Standard Preferred Authorized Online Dealer
We Only Ship Showroom Quality products vs Builder Grade quality found at big box retailers
All metal parts, not plastic like some of our competitors
Customer Care Experts Available 7 Days a Week to Serve You Before & After Purchase
A Showroom Experience from the Comfort of Your Home or Office
Â
Additional American Standard Links
View the Manufacturer Warranty
Browse all American Standard Products
American Standard Colony Collection
Specifications
| Width | 21.938 in. |
| Length | 32.938 in. |
| Nominal Width | 22 in. |
| Flow Rate (GPM) | 1.5 |
| Water Connection | 1/2" |
| Nominal Length | 33 in. |
| Spout Reach | 8.5 in. |
| Backplate Depth | 6 in. |
| Gauge | 20 |
| Escutcheon Width | 10.375 in. |
| Basin Depth (Left) | 6 in. |
| Basin Depth (Right) | 6 in. |
| Basin Length (Left) | 14 in. |
| Basin Length (Right) | 14 in. |
| Basin Width (Left) | 15.938 in. |
| Basin Width (Right) | 15.938 in. |
| Drain Connection | 3.563 in. |
| Faucet Centers | 8 in. |
| Handle Height | 6.5 in. |
| Spout Height | 4.9 in. |
| Faucet Hole Size | 1.5 in. |
| Max Deck Thickness | 1 in. |
| Sink Length | 32.938 in. |
| Minimum Cabinet Size | 36 in. |
| Faucet Height | 6.5 in. |
| Sink Height | 6 in. |
| Sink Width | 21.938 in. |
| Spout Swivel | 360 Degrees |
| Material | Stainless Steel |
| Thermostat | Traditional |
| Insulation Type | Drop In |
| Handle Material | Metal |
| Number Of Handles | 1 |
| Apron Front | No |
| Drain Placement | Center |
| Overflow | No |
| Sound Dampening | Yes |
| Faucet Type | Kitchen Faucet |
| Handle Style | Lever |
| Faucet Holes | 3 |
| Number Of Bathers | 2 |
| Sink Material | Stainless Steel |
| Sink Shape | Rectangular |
| Spout Type | Swivel |
| Farmhouse | No |
| Pullout Spray | No |
| Basin Split | 50/50 |
| Undercoating | Yes |
| Faucet Material | Brass |
| Certifications | CSA, NSF, ASME |
| ADA | Yes |
| Manufacturer Warranty | Limited Lifetime |
| Low Lead Compliant | Yes |
| CA Drought Compliant | Yes |
| ASSE Code | A112.18.1, A112.19.3 |
| CSA Code | B125.1 |
| Escutcheon Included | Yes |
| Handshower Included | Yes |
| Installation Hardware Included | Yes |
| Drain Assembly Included | Yes |
| Basin Rack Included | No |
| Basket Strainer Included | No |
| Colander Included | No |
| Cutting Board Included | No |
| Faucet Included | Yes |
| Sidespray | No |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
