Product Features:
Fully covered under a 1-year warranty
Quick, quiet flushing – American Standard toilets are famously efficient and hushed
Industry-leading flushing system out-performs older toilets while using less than 1/2 the water
Elongated bowl shape – more comfortable than a round bowl
One-piece toilet – seamless, easier to keep clean; lends to a more refined look
Shorter-height bowl – appropriate for children and smaller adults
Top-spud flushometer triggers flushing
Perfected porcelain casting process and adjustable tank anchors
Straight-forward installation instructions are included with each toilet
100% factory flush tested – guaranteed to perform
Product Technologies / Benefits:
Powerful Siphoning Water Jet – A perfectly positioned water jet captures the circular flow of water for optimal performance with minimal energy loss (water doesn’t hit a flat spot and slow down). As waste and water exit, they are siphoned into the trapway for an unmatched push/pull one-two punch.
2-1/8″ Fully Glazed Trapway – Waste and water exit the toilet through a trapway that is fully glazed, which seals it and provides for a smooth surface that waste can in no way cling to. The 2-1/8” diameter chute, while slightly narrower than the American Standard Champion flushing system’s 2-3/8” trapway, can still flush up to 150 feet of toilet paper without clogging. Not that you’ll ever use that much.
Product Specifications:
Overall Height: 28-1/2″ (measured from the bottom of the base to the highest point on toilet)
Overall Length: 28-1/4″ (measured from back of the fixture to front of the rim)
Overall Width: 14″ (measured from furthest point left to furthest point right)
Bowl Height: 15″ (measured from bottom of base to bowl rim)
Rough In: 10″ – 12″ (measured from wall behind toilet to center of waste outlet in floor)
Trapway Size: 2-1/8″ (diameter of outlet for water/waste exiting the bowl)
Flow Rate: 1.28 GPF (gallons-per-flush)
Water Area: 10″ X 12″
Spud Placement: Top
Additional American Standard Links
View the Manufacturer Warranty
Browse all American Standard Products
American Standard Madera Collection
Specifications
| Height | 28.5 in. |
| Width | 14 in. |
| Depth | 28.25 in. |
| Product Weight | 1 lbs. |
| Gallons Per Flush | 1.28 |
| Spud Size | 1.5 in. |
| Bowl Height | 15 in. |
| Rough In | 10 in. |
| Trapway | 2.125 in. |
| Water Area | 10 x 12 |
| Insulation Type | Floor Mounted |
| Material | Vitreous China |
| Thermostat | Basic |
| Bowl Shape | Elongated |
| Configuration | One Piece |
| Spud Placement | Top |
| Flush Type | Siphon Jet |
| ADA | No |
| Collection | Madera |
| Approved for Commercial Use | Yes |
| CA Drought Compliant | Yes |
| TX Drought Compliant | Yes |
| Seat Included | No |
| Angle Supply Included | No |
| Color | White |
| Color Tone | Whites |
