Whether you are replacing your existing sink or creating your dream kitchen, the Quince double bowl cast iron sink from American Standard adds the perfect combination of rustic charm and versatility for every day and entertaining. Crafted from durable cast iron, this double bowl design retains heat for effective soaking and dish washing. With a smooth, glossy finish, the thick, nonporous enamel surface is easy to clean and resistant to stains, chips, and cracks. Available in 3 and 4 hole styles to accommodate multiple faucet configurations.
American Standard 77DB.33224 Features:
Cast iron double bowl sink
4 Hole faucet installation
9″ Deep basins
Drop-in installation
36″ Cabinet required for installation
Covered under American Standard’s limited lifetime warranty
American Standard 77DB.33224 Specifications:
Sink Length: 32-7/8″ (from left to right)
Sink Width: 22-1/4″ (from front to back)
Sink Height: 9″ (from top to bottom)
Basin Dimensions (Left): 13-1/2″ L x 16-1/8″ W
Basin Dimensions (Right): 13-1/2″ L x 16-1/8″ W
Faucet Holes: 4
Faucet Centers: 8″ (distance between the installation holes for the faucet handles)
Minimum Cabinet Size: 36″
Drain Connection: 3-9/16″
Additional American Standard Links
View the Manufacturer Warranty
Browse all American Standard Products
American Standard Quince Collection
Specifications
| Width | 22.25 in. |
| Height | 9 in. |
| Nominal Width | 23 in. |
| Faucet Centers | 8 in. |
| Faucet Hole Size | 1.375 in. |
| Drain Connection | 3.5625 in. |
| Length | 32.875 in. |
| Nominal Length | 33 in. |
| Minimum Cabinet Size | 36 in. |
| Basin Length (Left) | 13.5 in. |
| Basin Length (Right) | 13.5 in. |
| Basin Width (Left) | 16.125 in. |
| Basin Width (Right) | 16.125 in. |
| Thermostat | Transitional |
| Material | Cast Iron |
| Faucet Holes | 4 |
| Insulation Type | Drop In |
| Apron Front | No |
| Drain Placement | Center |
| Basin Split | 50/50 |
| Farmhouse | No |
| Number Of Bathers | 2 |
| Sink Shape | Rectangular |
| Faucet Installation Type | Deck Mounted |
| Corner Sink | No |
| Collection | Quince |
| Certifications | ASME, CSA |
| Country Of Origin | China |
| Manufacturer Warranty | Limited Lifetime |
| ASSE Code | A112.19.1 |
| CSA Code | B45.2 |
| Soap Dispenser Included | No |
| Basin Rack Included | No |
| Basket Strainer Included | No |
| Colander Included | No |
| Cutting Board Included | No |
| Faucet Included | No |
| Drainboard | No |
| Color | Brilliant White |
| Color Tone | Whites |
