Privacy: Privacy door hardware features a locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside.
Â
Features:
Tested to exceed ANSI/BHMA Grade 2 security requirements
Constructed of solid brass for durability and premium feel
Accommodates door thickness 1-3/8″ to 2″; up to 2-1/2″ with purchase of a thick door kit
Limited Lifetime Mechanical Warranty and Limited 25 Year Finish Warranty
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ – 2″
Handing: Reversible Left or Right
Handle Width: 1-1/4″
Handle Height: 2-7/16″
Handle Projection: 2-5/16″
Trim Width: 2-9/16″
Trim Height: 2-9/16″
Product Weight: 5 lbs
Latch Faceplate: Drive-In, Round Corner, or Square Corner
Additional Baldwin Links
View the Manufacturer Warranty
Browse all Baldwin Products
Baldwin Ellipse Collection
Specifications
| Material | Brass |
| Thermostat | Traditional |
| Handle Style | Knob |
| Concealed Screws | No |
| Handshower | Left, Reversible, Right |
| Latch Faceplate | Drive-In, Round Corner, Square Corner |
| Rosette Shape | Round |
| Solid Construction | Solid Brass |
| Function | Privacy |
| Handle Material | Metal |
| Panic Proof | No |
| Locking Mechanism | Thumbturn |
| Knob Shape | Egg |
| ADA | No |
| Collection | Reserve |
| Approved for Commercial Use | No |
| Manufacturer Warranty | 25 Year Finish, Limited Lifetime Mechanical |
| Fire Rated | No |
| BHMA Certification | Grade 2 |
| Product Weight | 5 lbs. |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2" |
| Backset | 2-3/8", 3-3/4", Adjustable 2-3/8" or 2-3/4" |
| Handle Height | 2.4375 in. |
| Cross Bore | 2-1/8" |
| Edge Bore | 1" |
| Handle Projection | 2.3125 in. |
| Trim Height | 2.5625 in. |
| Trim Width | 2.5625 in. |
| Handle Width | 1.25 in. |
| Color | Lifetime Polished Brass, Lifetime Polished Nickel, Lifetime Satin Brass, Matte Antique Nickel, Matte Brass & Black, Polished Brass, Polished Chrome, Satin Black, Satin Nickel, Venetian Bronze |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Nickel Tones, Silver Tones |
