Product Features:
Includes a single hinge in each order
Features precisely machined square corners
Tested for commercial strength application, ideal for use in office buildings or warehouses
Features a removable pin, allowing you to easily remove the door without having to uninstall hinges
Packaged with 8 – 12-24 x 1/2″ machine and 8 – 12 x 1-1/4″ wood, flat head screws for simple, out of the box installation
Constructed with 8 screw holes in an arc hole pattern arrangement for maximum mounting strength
Product Technologies/ Benefits:
Mounting Type: Mortise door hinges mount flush with the surface of your door, providing maximum strength with the least interference with door functionality. It is recommended that three hinges be used on doors up to and including 7-1/2 feet, with one additional hinge for each additional 2-1/2 feet. Be sure to check your current hinges before making a purchase.
Product Specifications:
Gauge: 0.18
Hinge Width: 4-1/2″
Hinge Height: 4-1/2″
Projection: 1/8″
Hinge Type: Ball Bearing
Removable Pin: Yes
Material: Steel
Additional Best Access Links
Browse all Best Access Products
Best Access FBB168 Collection
Specifications
| Material | Steel |
| Mounting Type | Mortise |
| Hinge Type | Ball Bearing |
| Hole Pattern | Template |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | Yes |
| Approved for Commercial Use | Yes |
| Collection | FBB168 |
| ANSI Certification | A156.1 |
| Certifications | ANSI |
| Usage Level | Heavy Duty |
| Gauge | 0.18 |
| Hinge Size | 4-1/2 x 4-1/2 in. |
| Corners | Square Corner |
| Color | Satin Chrome |
