Features:
Includes cabinet drawer profiles that have a static load capacity of 100 pounds and a dynamic capacity of 75 pounds
Drawer profile serves as drawer sides and is side mountedÂ
Single 3/4 extension slides
Simple insertion and removal
Intended for installation in either panel or face frame cabinets
3-dimensional front adjustment and easy cam height adjustment
Blumotion soft-close ready
Front, bottom, and rear drawer panels are customer provided
Specifications:
Drawer Length: 11″
Slide Length: 10.625″
Extension Type: 3/4 Extension
Weight Capacity: 100 lbs.
Minimum Cabinet Depth: 10.875″
Maximum Cabinet Height: 3.375
Material: Steel
ANSI/BHMA: 156.9 Grade 1 Standard
Blum, Inc. is a leading manufacturer of functional hardware for the kitchen cabinet and commercial casework industries specializing in lift systems, concealed hinges and drawer runner systems.
Additional Blum Links
Browse all Blum Products
Blum METABOX Collection
Specifications
| Height | 3.375 in. |
| Length | 10.625 in. |
| Nominal Length | 11 in. |
| Quantity | 1 |
| Length mm | 270 mm |
| Drainboard Length | 11 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Minimum Cabinet Depth | 10.875 in. |
| Material | Steel |
| Insulation Type | Bottom Mount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Extension Type | 3/4 Extension |
| Self Closing | No |
| Soft Close | Yes |
| Approved for Commercial Use | No |
| Collection | METABOX |
| Manufacturer Warranty | Limited Lifetime |
| BHMA Certification | Grade 1 |
| Color | White |
| Color Tone | Whites |
