Features:
Designed to support up to 100 pounds of weight
Concealed undermount construction adds stability and support
Provides maximum access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Blumotion: Blum’s patented soft-closing technology is an industry-standard, having found its way into the homes, garages and offices of customers all across the country. Its design has been adapted to be used in a variety of different hinge and drawer slide systems making it a system you can count on in any application within your home.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 18-1/2″
Slide Length: 18″
Drawer Thickness: 5/8”
Soft Close: Yes
Extension: Type: Full Extension
Slide Type: Concealed
Weight Capacity: 100 lb
Material: Zinc
Cabinet Type: Face Frame, Panel
Quantity: 2
Screws not included
Installation and Adjustment Guides
Depth Adjustment
Â
Height and Tilt Adjustment
Â
Side to Side Adjustment
Â
Side Stabilisation Assembly
Â
Product Variations:
B563H2290B10: 10 Inch Drawer Slide
563H3050B: 12 Inch Drawer Slide
563H3810B: 15 Inch Drawer Slide
563H4570B (This Model): 18 Inch Drawer Slide
B562H533: 22 Inch Drawer Slide
Additional Blum Links
Browse all Blum Products
Blum TANDEM Collection
Specifications
| Length | 18 in. |
| Extension | 18.5313 in. |
| Quantity | 2 |
| Minimum Clearance | .8125 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Drainboard Length | 18.5 in. |
| Minimum Cabinet Depth | 21 in. |
| Material | Zinc |
| Insulation Type | Undermount |
| Mounting Type | Concealed Undermount |
| Adjustable | No |
| Self Closing | No |
| Soft Close | Yes |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Extension Type | Full Extension |
| Push to Open | No |
| Detent | No |
| Disconnect Style | Lever |
| Slide Type | Concealed |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | No |
| Series | TANDEM |
| BHMA Certification | Grade 1 |
| Installation Hardware Included | No |
| Color | Zinc Plated |
| Color Tone | Greys |
