Features:
Designed to support up to 100 pounds of weight
Concealed undermount construction adds stability and support
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
TANDEM: Blum’s TANDEM technology is a culmination all of the features, engineering innovations and end-user benefits that Blum has developed since Its inception. The first time you open and close a fully loaded Blum-equipped drawer, you’ll quickly realize that TANDEM is a runner system that is unmatched in quality, style and running action.
Self Closing: Gently push on the door front to engage the integrated spring mechanism. Once activated, these slides will close the drawer for you in one smooth movement.
Blumotion: Blum’s patented soft-closing technology is an industry standard, having found its way into the homes, garagesandoffices of customers all across the country. Itsdesign has been adapted to be used in a variety of different hinge and drawer slide systems making it a system you can count on in any application within your home.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 21-1/2″
Slide Length: 21″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 100 lbs
Material: Zinc
Cabinet Type: Face Frame, Panel
Quantity: 2
Installation and Adjustment Guides
Depth Adjustment
Â
Height and Tilt Adjustment
Â
Side to Side Adjustment
Â
Side Stabilisation Assembly
Â
Product Variations:
B563H2290B10: 10 Inch Drawer Slide
563H3050B: 12 Inch Drawer Slide
563H3810B: 15 Inch Drawer Slide
563H4570B: 18 Inch Drawer Slide
B562H533: 21 Inch Drawer Slide
563H5330B (This Model):Â 21 Inch Drawer Slide with Soft Close
Additional Blum Links
Browse all Blum Products
Blum TANDEM Collection
Specifications
| Material | Zinc |
| Insulation Type | Undermount |
| Mounting Type | Concealed Undermount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Self Closing | Yes |
| Soft Close | Yes |
| Adjustable | No |
| Push to Open | No |
| Extension Type | Full Extension |
| Detent | No |
| Disconnect Style | Lever |
| Slide Type | Concealed |
| Approved for Commercial Use | No |
| Manufacturer Warranty | Limited Lifetime |
| Series | TANDEM |
| BHMA Certification | Grade 1 |
| Length | 21 in. |
| Quantity | 2 |
| Extension | 21 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Drainboard Length | 21.5 in. |
| Minimum Cabinet Depth | 24 in. |
| Color | Zinc Plated |
| Color Tone | Greys |
