Features:
Includes a single (1) hinge in each order
Constructed of high quality steel for durability and dependability
Covered by Blum’s limited lifetime manufacturer warranty
Soft close function ensures your cabinet door will close quietly
2-way adjustable hinge for easy and customizable installation
Designed for a 155 degree opening angle
All necessary mounting hardware is included
Specifications:
Hinge Mount: Full Overlay, Partial Overlay
Opening Angle: 155
Material: Steel
Installation Type: Press-In
Cup Diameter: 1-3/8″
Bore Distance Min/Max: 3″, 8″
Cup Depth: 7/16″
Mount Centers: 1-3/4″
Product Technologies:
Concealed Hinge: Modernize your kitchen cabinets with a concealed hinge to create a seamless design and a new smooth functionality and feel. It’s important to know your desired overlay measurements and size compatibility before ordering, but once a successful installation is completed, you’ll be amazed at the big difference a small upgrade can make.
Material – Steel: Steel is cheap strong and durable making it a favorite for hinges of all types. Though it is more prone to rusting than solid brass or stainless steel.
Mounting Type – Press-In: Press-in hinges are equipped with pre-mounted dowels that fit into holes drilled directly into the cabinet door. They do not require any screws, and generally make for quick installation and replacement.
BLUMOTION: BLUMOTION is the soft close system from Blum. Whether large or small, heavy or light, BLUMOTION soft closing action keeps doors and drawers from slamming closed. It adapts to various closing speeds and features overload safety which protects the system from damage through use.
Mounting Type – INSERTA™: Blum’s unique INSERTA™ system simplifies installation by using specialized expanding dowels with a push down lever and pre-drilled holes. Once the dowel have been inserted into the holes, just push down the lever to cause the dowels to expand and create a secure fitting. No tools needed once the holes have been drilled.
Additional Blum Links
Browse all Blum Products
Blum CLIP Top Collection
Specifications
| Material | Steel |
| Insulation Type | Press-In |
| Assembly Required | No |
| Bulk Pack | No |
| Adjustable | Yes |
| Hinge Type | Concealed Euro, Partial Overlay |
| Soft Close | Yes |
| Cabinet Type | Face Frame |
| 3-Way Adjustable | No |
| Adjustable Depth | Yes |
| Adjustable Height | No |
| Adjustable Side to Side | Yes |
| Arm Type | Half Cranked |
| Demountable | No |
| Hinge Mount | Full Overlay, Partial Overlay |
| Push to Open | No |
| Self Closing | Yes |
| Soft Close Deactivation | Yes |
| Approved for Commercial Use | No |
| Country Of Origin | Austria, Brazil, USA |
| Made in America | Yes |
| Collection | CLIP Top BLUMOTION |
| Manufacturer Warranty | Limited Lifetime |
| Series | Clip Top 155° |
| BHMA Certification | Grade 1 |
| Product Weight | 0.5 lbs. |
| Quantity | 1 |
| Angle | 155 Degrees |
| Bottom Diameter | 3, 8 mm |
| Cup Depth | 0.46 in. |
| Cup Depth mm | 11.7 mm |
| Cup Diameter | 1.38 in. |
| Cup Diameter mm | 35 mm |
| Max Cabinet Door Thickness | 0.9375 in. |
| Max Cabinet Door Thickness mm | 24 mm |
| Mount Centers | 1.77 in. |
| Mount Centers mm | 45 mm |
| Opening Angle | 155 |
| Overlay | Partial |
| Installation Hardware Included | Yes |
| Color | Nickel |
