Features:
Includes a single (1) hinge in each order
Constructed of high quality steel for durability and dependability
Covered by Blum’s limited lifetime manufacturer warranty
Soft close function ensures your cabinet door will close quietly
2-way adjustable hinge for easy and customizable installation
Designed for a 95 degree opening angle
Demountable to allow for quick and easy removal of the cabinet door for cleaning or other purposes
All necessary mounting hardware is included
Specifications:
Hinge Mount: Full Inset
Opening Angle: 95
Material: Steel
Installation Type: Press-In
Cup Diameter: 1-3/8″
Bore Distance Min/Max: 3″, 7″
Cup Depth: 1/2″
Mount Centers: 1-3/4″
Product Technologies:
Concealed Hinge: Modernize your kitchen cabinets with a concealed hinge to create a seamless design and a new smooth functionality and feel. It’s important to know your desired overlay measurements and size compatibility before ordering, but once a successful installation is completed, you’ll be amazed at the big difference a small upgrade can make.
Material – Steel: Steel is cheap strong and durable making it a favorite for hinges of all types. Though it is more prone to rusting than solid brass or stainless steel.
Mounting Type – Press-In: Press-in hinges are equipped with pre-mounted dowels that fit into holes drilled directly into the cabinet door. They do not require any screws, and generally make for quick installation and replacement.
BLUMOTION: BLUMOTION is the soft close system from Blum. Whether large or small, heavy or light, BLUMOTION soft closing action keeps doors and drawers from slamming closed. It adapts to various closing speeds and features overload safety which protects the system from damage through use.
Additional Blum Links
Browse all Blum Products
Blum CLIP Top Collection
Specifications
| Material | Steel |
| Insulation Type | Press-In |
| Adjustable | Yes |
| Assembly Required | No |
| Soft Close | Yes |
| Adjustable Height | No |
| Cabinet Type | Panel (Frameless), Face Frame |
| Bulk Pack | No |
| 3-Way Adjustable | No |
| Adjustable Depth | Yes |
| Adjustable Side to Side | Yes |
| Arm Type | Full Cranked |
| Demountable | Yes |
| Hinge Mount | Full Inset |
| Hinge Type | Concealed Euro, Inset |
| Self Closing | Yes |
| Soft Close Deactivation | Yes |
| Push to Open | No |
| Collection | CLIP Top BLUMOTION |
| Approved for Commercial Use | No |
| Country Of Origin | Austria, Brazil, USA |
| Manufacturer Warranty | Limited Lifetime |
| Made in America | Yes |
| Series | CLIP Top 95° |
| BHMA Certification | Grade 1 |
| Installation Hardware Included | Yes |
| Quantity | 1 |
| Opening Angle | 95 |
| Bottom Diameter | 3, 7 mm |
| Cup Depth | 0.51 in. |
| Cup Diameter | 1.38 in. |
| Max Cabinet Door Thickness | 1.1875 in. |
| Max Cabinet Door Thickness mm | 30 mm |
| Overlay | Inset |
| Inset | Full |
| Mount Centers | 1.77 in. |
| Angle | 95 Degrees |
| Cup Depth mm | 13 mm |
| Cup Diameter mm | 35 mm |
| Mount Centers mm | 45 mm |
| Color | Nickel |
| Color Tone | Nickel Tones |
