Features:
Enables drawers to be opened by simply touching drawer front
Drawer motion is mechanical, smooth, and closes again with a light nudge
Tip-On works with slides that support a max of 88 lbs (11″ to 22″ slides) or 155 lbs (18″ to 24″ slides)
Works with panel and face frame cabinets, with widths from 24″ to 48″ wide
Four-dimensional adjustment and easy installation
Tip-On Blumotion synchronization rod sold separately (Product T60.000D)
Product Technologies:
BLUMOTION: Blum’s patented soft-closing technology is an industry standard, having found its way into the homes, garages and offices of customers all across the country. Its design has been adapted to be used in a variety of different hinge and drawer slide systems making it a system you can count on in any application within your home.
TIP-ON Touch To Open: A mechanical (not electrical) opening support system that allows the user to lightly touch the door front to completely open the drawer. The drawer motion is incredibly smooth, precise and works equally well across a wide range of drawer widths and weight. A light push to the front of the drawer will engage the close mechanism and reverse the process.
Specifications:
Drawer Length: 11″ to 21″
Weight Capacity: 155 lbs
Material: Steel
ANSI/BHMA: 156.9 Grade 1
Additional Blum Links
Browse all Blum Products
Blum BLUMOTION Collection
Specifications
| Max Capacity (Pounds) | 155 lbs. |
| Quantity | 2 |
| Drainboard Length | 11, 24 in. |
| Adjustable | Yes |
| Insulation Type | Press Fit |
| Material | Steel |
| Soft Close | Yes |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Self Closing | Yes |
| Mounting Type | Bottom Mount |
| Detent | No |
| Approved for Commercial Use | No |
| Manufacturer Warranty | Limited Lifetime |
| BHMA Certification | Grade 1 |
| Color | Dust Gray |
| Color Tone | Greys |
