Bosch’s inventive ventilation systems keep mealtime fresh by quietly purifying the air while you cook. They’re beautifully designed to seamlessly integrate into any kitchen with under-the cabinet, chimney, island, pull-out and downdraft styles. You’ll breathe easier knowing that smoke, steam, grease and odors are quietly and effectively taken care of.
Bosch Cooking Quality
Features:
Blower outputs up to 300 CFM to keep your kitchen free of cooking fumes and odors
Mesh filters effectively trap and filter out unwanted smoke, odors, and grease
Hood can be converted to ductless ventilation for improved efficiency and flexible installation options
2 Halogen lights illuminate the cooking area
Complements items from the 500 Series collection
Slide controls allow you to easily set the power level of your range hood
This sleek, integrated pull-out hood allows the user to close the hood when not in use, which provides a flush-look with the surrounding cabinetry
Front stainless steel visor panel can be replaced with the user’s own custom strip to match surrounding cabinetry (Custom Strip Not Provided)
3 Speeds
Converts to recirculation mode with accessory kit (Separate Purchase Required)
Absorbs odors with charcoal replacement filters (Separate Purchase Required)
6″ round duct at discharge
Covered under a 1 year limited parts and labor manufacturer warranty
Specifications:
CFM: 117, 231, 300
Sones: 1, 3
Nominal Width: 30″
Width: 29-7/8″
Height: 11-9/16″
Depth: 11″
Duct Size: 6″ Round
Ceiling Height: 30″ – 30″
Height Above Cooktop: 24″ to 30″
Voltage: 120V
Additional Bosch Links
Browse all Bosch Products
Bosch 500 Series Collection
Specifications
| Depth | 11 in. |
| Height | 11.563 in. |
| Product Weight | 26 lbs. |
| Width | 29.875 in. |
| Nominal Width | 30 in. |
| Duct Size | 6" Round |
| CFM (High) | 300 |
| CFM | 117, 231, 300 |
| Height Above Cooktop | 24" to 30" |
| Ceiling Height (Max) | 30 in. |
| Ceiling Height (Min) | 30 in. |
| Insulation Type | Full Installation |
| Material | Stainless Steel |
| Thermostat | Contemporary |
| Number of Bulbs | 2 |
| Bubbler Type | Halogen |
| Control Type | Slide |
| Duct Discharge | Vertical |
| Blower Type | Internal |
| Filter Type | Mesh Filters |
| Panel Ready | No |
| Fingerprint Resistant | No |
| Collection | 500 Series |
| Country Of Origin | Italy |
| Manufacturer Warranty | 1 Year Limited Parts and Labor |
| ADA | No |
| Certifications | UL |
| Outdoor Approved | No |
| Voltage | 120 |
| Watts Per Bulb | 20 |
| Frequency | 60 Hertz |
| Sones | 1, 3 |
| Light Included | Yes |
| Available Without Blower | No |
| Convertible to Ductless / Recirculating | Yes |
| Ductless | No |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
