Product Features:
Manufactured and assembled in the United States of America
Faucet body and handles are covered under Chicago Faucet’s limited lifetime warranty
Constructed of solid brass
High quality chrome plated finish – finishes are covered under warranty for a year
Smooth single handle operation
Full flow classic laboratory needle spout outlet
Ceramic 1/4 turn operating cartridge – covered under warranty for 5 years
Mounting hardware not included
The Chicago Faucets Benefit:
Commercial Grade Faucet: When a product is marked as “commercial grade” it means it has been built specifically to stand the test of time, and has been factory tested to function flawlessly through constant and continuous use. It is expected that faucets used in a commerce fashion will see much more use, and inversely abuse than typical faucets you might see in a residential setting, so they are engineered to do just that. Using simple, yet reliable, designs coupled with the industry’s highest quality materials these faucets are some of the most reliable on the market. Although they are marketed as being ideal for commercial settings, the savvy home owner might take the quality found here and add a staple of functionality throughout the home as well.
Product Specifications:
Overall Height: 10 1/2″ (measured from mounting surface to highest point on faucet)
Spout Height: 5 5/8″ (measured from mounting surface to spout outlet)
Spout Reach: 4 7/8″ (measured from center of faucet body to center of spout outlet)
Required Installation Holes: 1
Maximum Deck Thickness: 1 1/2″
Rated Operating Temperature: 40 – 140 degrees
Rated Operating Pressure: 20 – 125 PSI
1 handle included with faucet
1/2″ Connection – designed for use with standard U.S. plumbing supply bibs
Codes and Compliances:
ASME A112.18.1/CSA B125.1
Additional Chicago Faucets Links
View the Manufacturer Warranty
Browse all Chicago Faucets Products
Specifications
| Height | 10.5 in. |
| Product Weight | 6 lbs. |
| Max Deck Thickness | 1.5 in. |
| Spout Height | 5.625 in. |
| Spout Reach | 4.875 in. |
| Water Connection | 3/8" |
| Material | Brass |
| Faucet Holes | 1 |
| Insulation Type | Deck Mounted |
| Handle Style | Cross |
| Mounting Type | Single Hole |
| Number Of Handles | 1 |
| Valve Type | Ceramic Disc |
| Handle Material | Metal |
| Approved for Commercial Use | Yes |
| Country Of Origin | USA |
| ADA | No |
| Low Lead Compliant | No |
| Made in America | Yes |
| Certifications | ASME, CSA |
| ASSE Code | A112.18.1 |
| CSA Code | B125.1 |
| Drain Assembly Included | No |
| Escutcheon Included | No |
| Handshower Included | Yes |
| Valve Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
