Product Features:
Faucet body constructed of brass
Covered under Chicago Faucet’s limited lifetime warranty
Premier finishing process – finishes will resist corrosion and tarnishing through everday use
Double handle operation – handles rest on 1/4 turn valves
Side spray with 48″ hose aids with a variety of kitchen tasks
Spout swivels 360-degrees providing greater access to more areas of the sink
High-arch gooseneck spout design provides optimal room under the faucet for any size task
ADA compliant – complies with the standards set forth by the Americans with Disabilities Act for bathroom faucets
Product Technologies / Benefits:
ECAST: Durable brass construction with total lead content equal to or less than 0.25% by weighted average
Quaturn: Rebuildable compression cartridge opens and closes 90°, closes with water pressure and features a square tapered stem
Product Specifications:
Overall Height: 13-1/8″ (measured from counter top to highest part of faucet)
Spout Height: 7-1/2″ (measured from counter top to spout outlet)
Spout Reach: 8″ (measured from center of faucet base to center of spout outlet)
Number of Holes Required for Installation: 4
Faucet Centers (Distance Between Handle Installation Holes): 8″
Flow Rate: 2.2 GPM (gallons-per-minute)
Maximum Deck Thickness: 1-1/8″
Two handles included with faucet
Designed for use with standard U.S. plumbing connections
All hardware needed for mounting is included with faucet
Codes and Compliances:
ASME A112.18.1/CSA B125.1
Certified to NSF/ANSI 61, Section 9 by CSA
ADA ANSI/ICC A117.1
About Chicago Faucets:
Chicago Faucets, a member of the Geberit Group, has been a company that the nation has relied on for over a century to craft the highest quality and reliable plumbing products. They offer a complete range of products for schools, laboratories, hospitals, office buildings, food service, airports and sporting facilities. It is one of the only manufacturers left today that can say they engineer and assemble their faucets in the United States of America. Through constant innovation, such as the patented ECAST material and Quaturn cartridges, Chicago Faucets has not only stayed at the top of the industry, but has revolutionized it in many ways. With a focus in commercial grade faucets they truly exemplify durability and dependability in every one of their products.
Additional Chicago Faucets Links
View the Manufacturer Warranty
Browse all Chicago Faucets Products
Chicago Faucets Manual Collection
Specifications
| Thermostat | Basic |
| Material | Brass |
| Insulation Type | Deck Mounted |
| Valve Type | Ceramic Disc |
| Handle Material | Metal |
| Handle Style | Lever |
| Faucet Holes | 4 |
| Faucet Type | Kitchen Faucet |
| Number Of Handles | 2 |
| Pre Rinse | No |
| Pullout Spray | No |
| Approved for Commercial Use | Yes |
| Certifications | ANSI, ASME, NSF, CSA |
| ADA | Yes |
| Low Lead Compliant | Yes |
| CA Drought Compliant | No |
| Eco Friendly | No |
| Lead Leaching Certified NSF/ANSI 61 | Yes |
| ASSE Code | A112.18.1 |
| CSA Code | B125.1 |
| Height | 13.125 in. |
| Faucet Centers | 8 in. |
| Flow Rate (GPM) | 2.2 |
| Max Deck Thickness | 1.125 in. |
| Spout Height | 7.5 in. |
| Spout Reach | 8 in. |
| Handshower Included | Yes |
| Drain Assembly Included | No |
| Valve Included | Yes |
| Escutcheon Included | No |
| Filtering | No |
| Sidespray | Yes |
| Soap Dispenser Included | No |
| Color | Chrome |
| Color Tone | Silver Tones |
