Product Features:
Faucet body and handles are covered under Chicago Faucet’s limited lifetime warranty
Constructed of solid brass
High quality chrome plated finish – finishes are covered under warranty for a year
Self-closing lever handle operation
Metering cartridge – covered under 5-year warranty
Anti-rotational pins – for optional field installation
Anti-microbial flexible mouth guard
ADA compliant
Low lead compliant – meeting federal and state regulations for lead content
Standard U.S. 1/2″ supply inlet and coupling nut to fit 1/2″ and 3/8″ flexible risers
Mounting hardware not included
The Chicago Faucets Benefit:
ECAST Construction: With the threat of lead pollution in the public’s supply of drinking water, Chicago Faucets was one of the industry’s first to take the lead in finding a solution. These faucets are made of the same durable, high quality materials and fittings as always, however they are manufactured with .25% or less total lead content by weighted average. This means their faucets not only meet the strict guidelines first introduced by states like California and Virginia, but it surpasses those standards, coming as close to truly lead-free as possible.
Product Specifications:
Overall Height: 4″ (measured from mounting surface to highest point on faucet)
Spout Height: 2″ (measured from mounting surface to spout outlet)
Spout Reach: 3 1/4″ (measured from center of faucet body to center of spout outlet)
Required Installation Holes: 1
Maximum Deck Thickness: 1 1/2″
Rated Operating Temperature: 40 – 140 degrees
Rated Operating Pressure: 20 – 125 PSI
1 handle included with faucet
1/2″ Connection – designed for use with standard U.S. plumbing supply bibs
Codes and Compliances:
ASME A112.18.1/CSA B125.1
Certified to NSF/ANSI 61, Section 9 by CSA
ADA ANSI/ICC A117.1
Additional Chicago Faucets Links
View the Manufacturer Warranty
Browse all Chicago Faucets Products
Specifications
| Approved for Commercial Use | Yes |
| ADA | Yes |
| Country Of Origin | USA |
| Lead Leaching Certified NSF/ANSI 61 | Yes |
| Certifications | NSF, ANSI, ASME, CSA |
| ASSE Code | A112.18.1 |
| CSA Code | B125.1 |
| Low Lead Compliant | Yes |
| Made in America | Yes |
| Height | 4 in. |
| Width | 2 in. |
| Product Weight | 2.8 lbs. |
| Water Connection | 1/2" |
| Spout Height | 2 in. |
| Spout Reach | 3.25 in. |
| Max Deck Thickness | 1.5 in. |
| Material | Brass |
| Faucet Holes | 1 |
| Handle Style | Lever |
| Number Of Handles | 1 |
| Valve Type | Solenoid |
| Mounting Type | Single Hole |
| Handle Material | Metal |
| Handshower Included | Yes |
| Valve Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
