Product Features:
Manufactured and assembled in the United States of America
Faucet body and handles are covered under Chicago Faucet’s limited lifetime warranty
Constructed of solid brass
High quality chrome plated finish – finish covered under warranty for a year
Push button operation – handle is both metering and vandal resistant
Metering cartridge – covered under 5-year warranty
Anti-rotational pins – for optional field installation
ADA compliant
Low lead compliant – meeting federal and state regulations for lead content
Standard U.S. 1/2″ supply inlet and coupling nut to fit 1/2″ or 3/8″ flexible riser
Mounting hardware not included
The Chicago Faucets Benefit:
ECAST Construction: With the threat of lead pollution in the public’s supply of drinking water, Chicago Faucets was one of the industry’s first to take the lead in finding a solution. These faucets are made of the same durable, high quality materials and fittings as always, however they are manufactured with .25% or less total lead content by weighted average. This means their faucets not only meet the strict guidelines first introduced by states like California and Virginia, but it surpasses those standards, coming as close to truly lead-free as possible.
Product Specifications:
Overall Height: 4-7/8″ (measured from mounting surface to highest point on faucet)
Spout Height: 2″ (measured from mounting surface to spout outlet)
Spout Reach: 3-1/4″ (measured from center of faucet body to center of spout outlet)
Required Installation Holes: 1
Maximum Deck Thickness: 3-5/8″
Rated Operating Pressure: 20-125 PSI
Rated Operating Temperature: 40-140 – degrees Fahrenheit
Codes and Compliance:
ASME A112.18.1/CSA B125.1
Certified to NSF/ANSI 61, Section 9 by CSA
California Health and Safety Code 116875 (AB1953-2006)
Vermont Bill S.152
NSF/ANSI 372 Low Lead Content
ADA ANSI/ICC A117.1
Additional Chicago Faucets Links
View the Manufacturer Warranty
Browse all Chicago Faucets Products
Specifications
| Width | 2 in. |
| Flow Rate (GPM) | .7 |
| Max Deck Thickness | 1.5 in. |
| Approved for Commercial Use | Yes |
| ADA | Yes |
| ASSE Code | A112.18.1M |
| Certifications | NSF, ASME, CSA |
| CSA Code | B125 |
| Lead Leaching Certified NSF/ANSI 61 | Yes |
| Low Lead Compliant | Yes |
| Insulation Type | Deck Mounted |
| Faucet Holes | 1 |
| Handle Style | Push Button |
| Number Of Handles | 1 |
| Valve Type | Metering |
| Handshower Included | Yes |
| Valve Included | Yes |
| Volume Control | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
