Product Features:
Manufactured and assembled in the United States of America
Faucet body and handles are covered under Chicago Faucet’s
Constructed of solid brass
High quality chrome plated finish – finishes are covered under warranty for a year
Threaded outlet – 3/4″ hose thread
Unrestricted full-flow outlet
Single handle operation
Quaturn compression operating cartridge – covered under warranty for 5 years
Atmospheric vacuum breaker – not intended for continuous pressure applications
Threaded inlet connection with integral flange
ADA compliant
Mounting hardware not included
The Chicago Faucets Benefit:
Commercial Grade Faucet: When a product is marked as “commercial grade” it means it has been built specifically to stand the test of time, and has been factory tested to function flawlessly through constant and continuous use. It is expected that faucets used in a commerce fashion will see much more use, and inversely abuse than typical faucets you might see in a residential setting, so they are engineered to do just that. Using simple, yet reliable, designs coupled with the industry’s highest quality materials these faucets are some of the most reliable on the market. Although they are marketed as being ideal for commercial settings, the savvy home owner might take the quality found here and add a staple of functionality throughout the home as well.
Quaturn Cartridge: The Quaturn cartridge was the industries first replaceable, completely self-contained valve cartridge. The cartridge allows the user to turn the water from full flow to off in just a quarter-turn. This unique cartridge was designed to close with the flow of the water rather than against it which reduces washer ware and virtually eliminates faucet drips. Although the Quaturn cartridge has been updated over the years to incorporate new technologies and materials it still holds true to its principals and is completely interchangeable with any Quaturn manufactured since 1913.
Product Specifications:
Faucet Height: 3-7/8″ (measured from mounting plate to top of spout)
Spout Reach: 5-5/8″ (measured from center of faucet body to center of spout outlet)
Required Installation Holes: 1
Rated Operating Pressure: 20-125 PSI
Rated Operating Temperature: 40-140 degrees Fahrenheit
1 handle included with faucet
1/2″ connection – designed for use with standard U.S. plumbing supply bibs
Codes and Compliances:
ASME A112.18.1/CSA B125.1
Additional Chicago Faucets Links
View the Manufacturer Warranty
Browse all Chicago Faucets Products
Chicago Faucets Manual Collection
Specifications
| Material | Brass |
| Faucet Holes | 1 |
| Insulation Type | Wall Mounted |
| Valve Type | Slow Compression |
| Handle Material | Metal |
| Handle Style | Cross |
| Number Of Handles | 1 |
| Pullout Spray | No |
| ADA | No |
| Approved for Commercial Use | Yes |
| Certifications | ASME, CSA |
| ASSE Code | A112.18.1 |
| CSA Code | B125.1 |
| Low Lead Compliant | No |
| Drain Assembly Included | No |
| Escutcheon Included | No |
| Handshower Included | Yes |
| Valve Included | Yes |
| Sidespray | No |
| Soap Dispenser Included | No |
| Vacuum Breaker | Yes |
| Faucet Hole Size | 2.125 in. |
| Spout Reach | 5.625 in. |
| Water Pressure (Max) | 125 PSI |
| Water Pressure (Min) | 20 PSI |
| Color | Chrome |
| Color Tone | Silver Tones |
