Features:
Exceeds criteria for BHMA Grade 1
All metal construction for enhanced durability and security
Reversible handing for maximum versatility
Covered under Copper Creek’s limited lifetime mechanical and 2 year finish warranties
Complies with standards of the Americans with Disabilities Act (ADA)
Specifications:
Cross Bore: 2-1/8″
Edge Bore: 1″
Handing: Reversible, left or right
Door Thickness: 1-3/8″ to 1-3/4″
Trim Height: 3-1/2″
Trim Width: 3-1/2″
Handle Projection: 2-3/4″
Additional Copper Creek Links
View the Manufacturer Warranty
Browse all Copper Creek Products
Copper Creek 9000 Series Collection
Specifications
Warranty and Product Information
| Approved for Commercial Use | Yes |
| ADA | Yes |
| Collection | Bulldog |
| Country Of Origin | Taiwan |
| Manufacturer Warranty | 2 Year Finish, Limited Lifetime Mechanical |
| Certifications | ANSI, UL |
| ANSI Certification | A156.2 |
| Series | 9000 Series |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
Dimensions and Measurements
| Height | 3.5 in. |
| Width | 3.5 in. |
| Product Weight | 1 lbs. |
| Projection | 2.75 in. |
| Edge Bore | 1" |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8" |
| Cross Bore | 2-1/8" |
| Rose Diameter | 3.5 in. |
| Lever Length | 5 in. |
Characteristics and Features
| Material | Brass, Steel, Zinc |
| Handshower | Reversible |
| Handle Style | Lever |
| Function | Storeroom |
| Cylinder | 6 Pin Schlage C |
Included Components
| Interchangeable Core | No |
| Color | Oil Rubbed Bronze, Satin Stainless |
| Color Tone | Bronze Tones, Stainless Steel |
