Corbin Russwin is represented by ASSA ABLOY Door Security Solutions
Lock Function:
Latchbolt operated by handle either side, when deadbolt is retracted
Deadbolt thrown or retracted by thumbturn inside or by emergency release tool outside
Does not allow for free egress
Features:
Exceeds criteria for BHMA Grade 1
All metal construction for enhanced durability and security
Reversible handing for easy installation
Includes a 10 year limited warranty
UL listed 3 hour rating
Compliant with Americans with Disabilities Act (ADA)
Specifications:
Backset: 2-3/4″
Handing: Left, Left Hand Reverse, Right, Right Hand Reverse
Door Thickness: 1-3/4″
Handle Length: 4″
Trim Projection: 2-5/8″
Trim Width: 2-1/4″
Trim Height: 2-1/4″
Latch Faceplate: Square Corner
Product Weight: 6.25 lbs.
Material: Brass, Stainless Steel, Steel
Additional Corbin Russwin Links
View the Manufacturer Warranty
Browse all Corbin Russwin Products
Corbin Russwin ML2000 Collection
Specifications
| Product Weight | 6.25 lbs. |
| Door Thickness | 1-3/4" |
| Trim Height | 2.25 in. |
| Trim Width | 2.25 in. |
| Backset | 2-3/4" |
| Handle Projection | 2.625 in. |
| Handle Length | 4 in. |
| Material | Brass, Stainless Steel, Steel |
| Thermostat | Transitional |
| Function | Privacy |
| Handshower | Left, Left Hand Reverse, Right, Right Hand Reverse |
| Latch Faceplate | Square Corner |
| Shape | Straight |
| Concealed Screws | Yes |
| Panic Proof | No |
| Locking Mechanism | Thumbturn |
| Rosette Shape | Round |
| Certifications | ANSI, UL |
| Collection | Armstrong |
| Country Of Origin | USA |
| Manufacturer Warranty | 10 Year Limited |
| Approved for Commercial Use | Yes |
| Series | ML2000 |
| ADA | Yes |
| Made in America | Yes |
| ANSI Certification | A156.13 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Color | Satin Chrome |
| Color Tone | Silver Tones |
