Corbin Russwin is represented by ASSA ABLOY Door Security Solutions
Lock Function:
Latchbolt operated by handle either side, unless outside handle is locked by key outside
Latchbolt operated by key when outside handle locked
Outside handle remains locked unless unlocked by key
Inside handle always free
Auxiliary latch deadlocks the latchbolt
Allows for free egress
Features:
Exceeds criteria for BHMA Grade 1
All metal construction for enhanced durability and security
Reversible handing for easy installation
Includes a 10 year limited warranty
UL listed 3 hour rating
Compliant with Americans with Disabilities Act (ADA)
Specifications:
Backset: 2-3/4″
Handing: Left, Left Hand Reverse, Right, Right Hand Reverse
Door Thickness: 1-3/4″
Handle Length: 4-13/16″
Trim Projection: 2-5/8″
Trim Height: 7-1/2″
Trim Width: 2-1/4″
Cylinder Included: No
Latch Faceplate: Square Corner
Product Weight: 6.25 lbs.
Material: Brass, Stainless Steel, Steel
Additional Corbin Russwin Links
View the Manufacturer Warranty
Browse all Corbin Russwin Products
Corbin Russwin ML2000 Collection
Specifications
| Product Weight | 6.25 lbs. |
| Door Thickness | 1-3/4" |
| Handle Projection | 2.625 in. |
| Trim Height | 7.5 in. |
| Trim Width | 2.25 in. |
| Backset | 2-3/4" |
| Handle Length | 4.8125 in. |
| Manufacturer Warranty | 10 Year Limited |
| Approved for Commercial Use | Yes |
| Collection | Newport |
| Country Of Origin | USA |
| Certifications | ANSI, UL |
| ADA | Yes |
| ANSI Certification | A156.13 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Series | ML2000 |
| Made in America | Yes |
| Material | Brass, Stainless Steel, Steel |
| Thermostat | Transitional |
| Handshower | Left, Left Hand Reverse, Right, Right Hand Reverse |
| Panic Proof | Yes |
| Concealed Screws | Yes |
| Function | Classroom |
| Latch Faceplate | Square Corner |
| Cylinder Type | Single Cylinder |
| Rosette Shape | Rectangle |
| Shape | Straight |
| Cylinder Included | No |
| Color | Satin Chrome |
