Corbin Russwin is represented by ASSA ABLOY Door Security Solutions
Lock Function:
Latchbolt operated by handle either side, unless outside handle is locked by thumbturn inside
Operating inside handle, closing door or operating emergency key outside unlocks outside
Inside handle always free
Allows for free egress
Features:
Exceeds criteria for BHMA Grade 1
All metal construction for enhanced durability and security
Reversible handing for easy installation
Includes a 10 year limited warranty
UL listed 3 hour rating
Compliant with Americans with Disabilities Act (ADA)
Specifications:
Backset: 2-3/4″
Handing: Left, Left Hand Reverse, Right, Right Hand Reverse
Door Thickness: 1-3/4″
Handle Length: 4-13/16″
Trim Projection: 2-5/8″
Trim Width: 2-1/4″
Trim Height: 2-1/4″
Latch Faceplate: Square Corner
Product Weight: 6.25 lbs.
Material: Brass, Stainless Steel, Steel
Additional Corbin Russwin Links
View the Manufacturer Warranty
Browse all Corbin Russwin Products
Corbin Russwin ML2000 Collection
Specifications
| Product Weight | 6.25 lbs. |
| Backset | 2-3/4" |
| Door Thickness | 1-3/4" |
| Handle Length | 4.8125 in. |
| Handle Projection | 2.625 in. |
| Trim Height | 2.25 in. |
| Trim Width | 2.25 in. |
| Material | Brass, Stainless Steel, Steel |
| Thermostat | Transitional |
| Shape | Straight |
| Concealed Screws | Yes |
| Function | Privacy |
| Handshower | Left, Left Hand Reverse, Right, Right Hand Reverse |
| Latch Faceplate | Square Corner |
| Locking Mechanism | Thumbturn |
| Panic Proof | Yes |
| Rosette Shape | Round |
| Certifications | ANSI, UL |
| Collection | Newport |
| Country Of Origin | USA |
| Manufacturer Warranty | 10 Year Limited |
| ADA | Yes |
| Approved for Commercial Use | Yes |
| Made in America | Yes |
| Series | ML2000 |
| ANSI Certification | A156.13 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Color | Satin Chrome, Satin Stainless Steel |
| Color Tone | Silver Tones, Stainless Steel |
