Corbin Russwin is represented by ASSA ABLOY Door Security Solutions
Lock Function:
Latchbolt operated by handle either side, unless outside handle is locked by thumbturn inside
Operating inside handle, closing door or operating emergency key outside unlocks outside
Inside handle always free
Allows for free egress
Features:
Exceeds criteria for BHMA Grade 1
All metal construction for enhanced durability and security
Reversible handing for easy installation
Includes a 10 year limited warranty
UL listed 3 hour rating
Compliant with Americans with Disabilities Act (ADA)
Specifications:
Backset: 2-3/4″
Handing: Left, Left Hand Reverse, Right, Right Hand Reverse
Door Thickness: 1-3/4″
Handle Length: 4-13/16″
Trim Projection: 2-5/8″
Trim Height: 7-1/2″
Trim Width: 2-1/4″
Latch Faceplate: Square Corner
Product Weight: 6.25 lbs.
Material: Brass, Stainless Steel, Steel
Additional Corbin Russwin Links
View the Manufacturer Warranty
Browse all Corbin Russwin Products
Corbin Russwin ML2000 Collection
Specifications
| Material | Brass, Stainless Steel, Steel |
| Thermostat | Transitional |
| Function | Privacy |
| Handshower | Left, Left Hand Reverse, Right, Right Hand Reverse |
| Latch Faceplate | Square Corner |
| Shape | Straight |
| Rosette Shape | Rectangle |
| Concealed Screws | Yes |
| Locking Mechanism | Thumbturn |
| Panic Proof | Yes |
| ADA | Yes |
| Collection | Newport |
| Approved for Commercial Use | Yes |
| ANSI Certification | A156.13 |
| Certifications | ANSI, UL |
| Country Of Origin | USA |
| Made in America | Yes |
| Manufacturer Warranty | 10 Year Limited |
| Series | ML2000 |
| BHMA Certification | Grade 1 |
| Fire Rated | Yes |
| Product Weight | 6.25 lbs. |
| Backset | 2-3/4" |
| Door Thickness | 1-3/4" |
| Handle Projection | 2.625 in. |
| Handle Length | 4.8125 in. |
| Trim Height | 7.5 in. |
| Trim Width | 2.25 in. |
| Color | Satin Chrome |
| Color Tone | Silver Tones |
