Two keys will be shipped per lock. Three or more items keyed alike will ship a total of 6 keys
Corbin Russwin is represented by ASSA ABLOY Door Security Solutions
Lock Function:
Latchbolt operated by handle either side, unless outside handle locked by projection of deadbolt
Inside handle simultaneously retracts latchbolt and deadbolt and unlocks outside
Inside handle always free
Deadbolt thrown or retracted by key outside or by thumbturn inside
Allows for free egress
Features:
Exceeds criteria for BHMA Grade 1
All metal construction for enhanced durability and security
Reversible handing for easy installation
Includes a 10 year limited warranty
UL listed 3 hour rating
Compliant with Americans with Disabilities Act (ADA)
Specifications:
Backset: 2-3/4″
Handing: Left, Left Hand Reverse, Right, Right Hand Reverse
Door Thickness: 1-3/4″
Handle Length: 4-13/16″
Trim Projection: 2-5/8″
Trim Height: 7-1/2″
Trim Width: 2-1/4″
Cylinder Included: No
Latch Faceplate: Square Corner
Product Weight: 6.25 lbs.
Material: Brass, Stainless Steel, Steel
Additional Corbin Russwin Links
View the Manufacturer Warranty
Browse all Corbin Russwin Products
Corbin Russwin ML2000 Collection
Specifications
| Material | Brass, Stainless Steel, Steel |
| Thermostat | Transitional |
| Rosette Shape | Rectangle |
| Shape | Straight |
| Concealed Screws | Yes |
| Function | Keyed Entry |
| Handshower | Left, Left Hand Reverse, Right, Right Hand Reverse |
| Latch Faceplate | Square Corner |
| Locking Mechanism | Thumbturn |
| Panic Proof | Yes |
| Cylinder Type | Single Cylinder |
| Collection | Newport |
| Approved for Commercial Use | Yes |
| ADA | Yes |
| Country Of Origin | USA |
| Certifications | ANSI, UL |
| Manufacturer Warranty | 10 Year Limited |
| Made in America | Yes |
| Fire Rated | Yes |
| Series | ML2000 |
| BHMA Certification | Grade 1 |
| ANSI Certification | A156.13 |
| Product Weight | 6.25 lbs. |
| Door Thickness | 1-3/4" |
| Handle Projection | 2.625 in. |
| Trim Height | 7.5 in. |
| Trim Width | 2.25 in. |
| Backset | 2-3/4" |
| Handle Length | 4.8125 in. |
| Cylinder Included | No |
| Color | Satin Chrome |
| Color Tone | Silver Tones |
