Product Features:
Quiet action, Teck exposed diaphragm flush valve
Vandal resistant cover screw
Metal (non hold open) ADA Compliant oscillating handle
Vacuum breaker
Renewable seat
Chloramine resistant diaphragm attached to guide with forged metal retainer
Spud flange and concealed spud nut
For flushing urinals with 3/4″ top spud
Maximum 330mm(13″) from centerline of valve inlet to top of urinal
1″ FIP 3/4″ Copper sweat inlet adaptor for angle check stop with protecting cap
Adjustable 121mm (4.75”) plus or minus 11mm (7/16”) inlet/valve outlet centers
Cover tube and S/S wall flange
Factory Set to 1.9L (0.50 Gal.) – not field adjustable
Product Certifications:
IAPMO listed to CSA B125.3/ ASSE 1037
ADA compliant to meet Handicapped Accessibility Standard ICC/ANSI A117.1 of less than 5 lbs operating force
CEC flow rate compliant when paired with non-wall mounted urinals. Non-compliant when paired with wall mounted urinals – CEC regulation requires 0.125 GPF
Additional Delta Links
View the Manufacturer Warranty
Browse all Delta Products
Delta Commercial Collection
Specifications
| Height | 15.4 in. |
| Product Weight | 3.1 lbs. |
| Gallons Per Flush | 0.5 |
| Spud Size | .75 in. |
| Material | Brass |
| Insulation Type | Urinal |
| Handle Style | Lever |
| Handle Material | Metal |
| Configuration | Concealed |
| Control Type | Manual |
| Spud Placement | Top |
| Approved for Commercial Use | Yes |
| Collection | Commercial |
| Country Of Origin | Canada |
| ADA | Yes |
| CA Drought Compliant | No |
| Made in America | Yes |
| TX Drought Compliant | Yes |
| Handshower Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
