Product Features:
Pressure Balance cartridge
Limit stop for pre-setting Maximum temperature
Integral checks in the cartridge prevent crossflow between Hot and Cold water inlets
Non-Removable Blue/Red visual cover indicator for Cold, Mixing and Hot handle positions
Standard 24″ Stainless Steel Bar with ADA Slide handshower and shower diverter valve-backflow protection provided by two integral check valves in handshower
ADA Compliant diverter handle
Handshower Flow Rates as listed unless optional Handshower #2 selected
Handshower MAX: 1.5 GPM @ 80 PSI (5.7 L/min @ 552 kPa)
Handshower MIN: 1.13 GPM @ 45 PSI (4.3 L/min @ 310 kPa)
Handle#: 2 – Metal Lever Handle – ADA compliant – 85mm (3.33″)
Optional 1753 mm (69″) Long Chrome plated Brass Double Spiral Hose (replaces standard hose)
No fixed shower outlet supplied
Product Certifications:
ASME A112.18.1 / CSA B125.1
Pressure Balance Valve ASSE 1016
Pressure Balance and Diverter lever handles ADA compliant to ICC/ANSI A117.1/ADA
Handshower backflow protection provided by two integral certified check valves in series, which operate independently, ASME A112.18.3
Handshower ADA compliant to ICC/ANSI A117.1/ADA
Additional Delta Links
View the Manufacturer Warranty
Browse all Delta Products
Delta Commercial Collection
Specifications
| Material | Brass |
| Thermostat | Basic |
| Insulation Type | Wall Mounted |
| Handle Style | Lever |
| Number Of Handles | 2 |
| Valve Type | Pressure Balanced |
| Spray Pattern | Full |
| Spray Settings | 1 |
| Scald Guard | Yes |
| Handle Material | Metal |
| Handshower | Single Function |
| Diverter Location | Wall Mounted |
| Country Of Origin | USA |
| Approved for Commercial Use | Yes |
| Collection | Commercial |
| ADA | Yes |
| CA Drought Compliant | Yes |
| Made in America | Yes |
| Flow Rate (GPM) | 1.5 |
| Hose Length | 69 in. |
| Handshower Included | Yes |
| Valve Included | No |
| Hose Included | Yes |
| Slide Bar Included | Yes |
| Diverter Included | Yes |
| Wall Supply Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
