Elkay 9-3/8″ Low Lead Compliant ADA Single Hole Concealed Deck Utility Faucet with 12″ Reach Arc Tube Spout and 4″ Blade Handles
All varieties of Elkay faucets are precision crafted and specially designed for durability and ease of cleaning. Elkay offers seamlessly integrated function with your sense of style. Elkay faucets meet your specific needs while adding the finishing touch to your room’s decor.
Product Features:
Three hole dual handle under counter mount faucet
Quarter turn ceramic disc cartridge
Solid brass construction
Chrome finish
Includes spout swing restriction pin
Ship wt. 5.5 lbs
Product Specifications:
Mounting Type: Concealed Deck
Handles: 2
Handles Included: Yes
Handle Type: 4″ Blade Handles
Holes Required: Three
Spout Type: 12″ Arc Tube
Overall Height: 9-3/8″
Spout Height: 3″
Spout Reach: 12″
Material: Brass
Valve Type: Qtr Ceramic Disc
Valve Connection: 3/8″ Compression Hose Assembly
Flow Rate: 2.2 GPM
Product Certifications and Compliances:
ASME 112.18.1/CSA B125-01
CSA B125-01
ANSI/NSF61 – Certified
ADA Compliant
IAPMO Listed
CA AB1953/VT S152 Low Lead Compliant
Additional Elkay Links
View the Manufacturer Warranty
Browse all Elkay Products
Specifications
| Approved for Commercial Use | Yes |
| ADA | Yes |
| Lead Leaching Certified NSF/ANSI 61 | Yes |
| Certifications | NSF, ASME, CSA |
| ASSE Code | A112.18.1 |
| CSA Code | B125-01 |
| Low Lead Compliant | Yes |
| CA Drought Compliant | No |
| Height | 9.38 in. |
| Faucet Centers | 8 in. |
| Flow Rate (GPM) | 2.2 |
| Spout Reach | 12, 3 in. |
| Inside Diameter | .38 in. |
| Hose Length | 12 in. |
| Material | Brass |
| Insulation Type | Deck Mounted |
| Faucet Holes | 3 |
| Handle Style | Wrist Blade |
| Number Of Handles | 2 |
| Valve Type | Ceramic Disc |
| Spout Style | Flexible |
| Handshower Included | Yes |
| Valve Included | Yes |
| Hose Included | Yes |
| Color | Chrome |
| Color Tone | Silver Tones |
