All Emtek items are made to order
Passage: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn’t needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.
Features:
Fully customizable
Constructed of solid brass and marble for durability and dependability
Installs easily with all necessary mounting hardware included
Covered by Emtek’s limited lifetime manufacturer warranty
Product Technologies:
Solid Brass Construction: This product begins with raw bars of solid brass which are heated, and pounded into specially made dies—producing a stronger, more substantial product. The difference between lesser metals and heat forged brass is noticeable the minute you hold it in your hands—solid brass is heavier, smoother, and naturally resists corrosion.
28 Degree Premium Latch: Emtek’s proprietary CF Mechanism design incorporates a unique chassis design that significantly shortens the rotation and creates a more crisp and ergonomic function.
Concealed Screws: Emtek knobs and levers that feature the CF Mechanism install cleanly on both the interior and exterior of the door, completely concealing all screws required for the installation. All you’ll ever see is the door and the hardware you’ve chosen for it—both seamlessly co-existing.
Specifications:
Backset: Adjustable 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-3/8″ to 2-7/8″
Handing: Reversible Left or Right
Handle Width: 2-1/4″
Handle Height: 2-1/4″
Handle Projection: 2-1/4″
Product Weight: 3.75 lbs.
Latch Faceplate: Round Corner or Square Corner
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek Green Marble Collection
Specifications
| Product Weight | 3.75 lbs. |
| Door Thickness | 1-1/2", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/4", 2-3/8", 2-5/8", 2-7/8" |
| Backset | 2-3/4", 2-3/8", Adjustable 2-3/8" or 2-3/4" |
| Cross Bore | 2-1/8" |
| Edge Bore | 1" |
| Handle Projection | 2.25 in. |
| Handle Width | 2.25 in. |
| Handle Height | 2.25 in. |
| Material | Brass, Marble |
| Thermostat | Modern |
| Handshower | Left, Reversible, Right |
| Function | Passage |
| Handle Style | Knob |
| Handle Material | Marble |
| Characteristics | Stone |
| Concealed Screws | Yes |
| Latch Faceplate | Round Corner, Square Corner |
| Knob Shape | Flat, Round |
| Solid Construction | Solid Brass |
| Trim Design | Disk, Modern Rectangular, Quincy, Square, Urban Modern, Watford, Wilshire |
| Handle Design | Green Marble |
| Collection | SELECT |
| Approved for Commercial Use | No |
| Country Of Origin | China |
| Fire Rated | No |
| Manufacturer Warranty | Limited Lifetime |
| Series | Green Marble |
| 28 Degree Latch | Yes |
| Color | Flat Black, Oil Rubbed Bronze, Polished Chrome, Polished Nickel, Satin Brass, Satin Nickel, Unlacquered Brass |
