All Emtek items are made to order. Please allow 1 to 2 weeks processing time.
Passage Function: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn’t needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.
Features:
Crafted from solid brass for a premium feel
This leverset is reversible for left or right handed doors
Easily installs on standard prepared doors
Covered by a Limited Lifetime Manufacturer Warranty
Does not meet criteria of the American’s with Disabilities Act (ADA)
Product Technologies:
Material – Solid Brass: Solid brass offers a substantial weight and smoothness compared to lesser materials. It is widely considered to be the highest quality material in door hardware.
CF Mechanism: Emtek’s proprietary CF Mechanism design incorporates a unique chassis design that significantly shortens the rotation and creates a more crisp and ergonomic function. This 28° latch mechanism comes standard with all units equipped with the CF Mechanism, affording a superior and robust operation.
Concealed Screws: Emtek knobs and levers that feature the CF Mechanism install cleanly on both the interior and exterior of the door, completely concealing all screws required for the installation. All you’ll ever see is the door and the hardware you’ve chosen for it both seamlessly co-existing.
Specifications:
Backset: 2-3/8″ or 2-3/4″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-1/4″ to 3″
Handing: Reversible, Left or Right
Handle Length: 5-3/8″
Handle Projection: 2-1/8″
Latch Faceplate: Round Corner, Square Corner
Material: Brass
Product Weight: 1.8 lbs.
Product Variations:
C505MYL: Dummy Door Lever Set
C510MYL (This Model): Passage Door Lever Set
C520MYL: Privacy Door Lever Set
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek Myles Collection
Specifications
| Material | Brass |
| Thermostat | Modern |
| Rosette Shape | Round |
| Solid Construction | Solid Brass |
| Concealed Screws | Yes |
| Function | Passage |
| Handshower | Left, Reversible, Right |
| Latch Faceplate | Round Corner, Square Corner |
| Lever Shape | Round, Straight |
| Handle Design | Myles |
| Panic Proof | No |
| Collection | Brass Modern |
| Approved for Commercial Use | No |
| ADA | No |
| Manufacturer Warranty | Limited Lifetime |
| Fire Rated | No |
| Series | Myles |
| Product Weight | 1.8 lbs. |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-1/4", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2", 2-1/4", 2-1/8", 2-3/4", 2-3/8", 2-5/8", 2-7/8", 3" |
| Handle Projection | 2.125 in. |
| Backset | 2-3/4", 2-3/8" |
| Edge Bore | 1" |
| Handle Length | 5.375 in. |
| Color | Flat Black, Lifetime Polished Nickel, Oil Rubbed Bronze, Polished Chrome, Satin Brass, Satin Nickel, Unlacquered Brass |
| Color Tone | Blacks, Brass Tones, Bronze Tones, Nickel Tones, Silver Tones |
