All Emtek items are made to order.
Passage Function: Passage door hardware has no locking mechanism. Both the interior and exterior handles are always free making it perfect for hallways, closet doors, and anywhere else a lock isn’t needed. Passage door hardware can also be used in conjunction with a deadbolt to secure a back door or entrance.
Features:
Crafted with solid bronze designed for lasting use
Finishes gracefully age, revealing the underlying bronze
Reversible handing installs on left or right handed doors
Installs on doors with 1-1/4″ to 3″ thickness
Includes round or square corner latch faceplate
All necessary mounting hardware is included for easy installation
Product Technologies:
Solid Bronze Construction: Solid bronze is made with copper and tin. Bronze is known for its appearance, resilience,and durability. Solid bronze is stronger and less brittle than cast iron and resists corrosion.
28 Degree Premium Latch: Emtek’s proprietary CF Mechanism design incorporates a unique chassis design that significantly shortens the rotation and creates a more crisp and ergonomic function.
Concealed Screws: Emtek knobs and levers that feature the CF Mechanism install cleanly on both the interior and exterior of the door, completely concealing all screws required for the installation. All you’ll ever see is the door and the hardware you’ve chosen for it—both seamlessly co-existing.
Specifications:
Backset: 2-3/4″ or 2-3/8″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-1/4″ to 3″
Handing: Reversible Left or Right
Handle Length: 5-5/16″
Handle Projection: 1-3/8″
Product Weight: 2 lbs.
Latch Faceplate: Square Corner or Round Corner
Material: Bronze
Product Variations:
C705MA: Dummy Lever Set
C710MA (This Model): Passage Lever Set
C720MA: Privacy Lever Set
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek Mariposa Collection
Specifications
| Thermostat | Modern, Rustic |
| Material | Bronze |
| Concealed Screws | Yes |
| Function | Passage |
| Handshower | Left, Reversible, Right |
| Latch Faceplate | Round Corner, Square Corner |
| Rosette Shape | Arch, Rectangle, Round, Square |
| Solid Construction | Solid Bronze |
| Lever Shape | Round, Straight |
| Handle Design | Mariposa |
| Collection | Rustic Sandcast Bronze |
| ADA | No |
| Country Of Origin | USA |
| Manufacturer Warranty | Limited Lifetime Mechanical |
| Approved for Commercial Use | No |
| Made in America | Yes |
| Fire Rated | No |
| Series | Mariposa |
| Product Weight | 2 lbs. |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-1/4", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/4", 2-3/8", 2-5/8", 2-7/8", 3" |
| Handle Projection | 1.375 in. |
| Handle Length | 5.3125 in. |
| Backset | 2-3/4", 2-3/8" |
| Edge Bore | 1" |
| 28 Degree Latch | Yes |
| Color | Flat Black Bronze, Medium Bronze, Tumbled White Bronze |
| Color Tone | Bronze Tones |
