All Emtek items are made to order.
Privacy Function: Privacy door hardware features a locking mechanism on the interior for use on bedroom and bathroom doors where locking is needed. The exterior side features a small pin hole to unlock the door hardware from the outside.
Features:
Crafted with solid bronze designed for lasting use
Finishes gracefully age, revealing the underlying bronze
Reversible handing installs on left or right handed doors
Installs on doors with 1-1/4″ to 3″ thickness
Includes round or square corner latch faceplate
All necessary mounting hardware is included for easy installation
Product Technologies:
Solid Bronze Construction: Solid bronze is made with copper and tin. Bronze is known for its appearance, resilience,and durability. Solid bronze is stronger and less brittle than cast iron and resists corrosion.
28 Degree Premium Latch: Emtek’s proprietary CF Mechanism design incorporates a unique chassis design that significantly shortens the rotation and creates a more crisp and ergonomic function.
Concealed Screws: Emtek knobs and levers that feature the CF Mechanism install cleanly on both the interior and exterior of the door, completely concealing all screws required for the installation. All you’ll ever see is the door and the hardware you’ve chosen for it—both seamlessly co-existing.
Specifications:
Backset: 2-3/4″ or 2-3/8″
Cross Bore: 2-1/8″
Edge Bore: 1″
Door Thickness: 1-1/4″ to 3″
Handing: Reversible Left or Right
Handle Length: 5-5/16″
Handle Projection: 1-3/8″
Product Weight: 2 lbs.
Latch Faceplate: Square Corner or Round Corner
Locking Mechanism: Trim Lock
Material: Bronze
Product Variations:
C705MA: Dummy Lever Set
C710MA: Passage Lever Set
C720MA (This Model): Privacy Lever Set
Additional Emtek Links
View the Manufacturer Warranty
Browse all Emtek Products
Emtek Mariposa Collection
Specifications
| Product Weight | 2 lbs. |
| Handle Projection | 1.375 in. |
| Backset | 2-3/4", 2-3/8" |
| Cross Bore | 2-1/8" |
| Door Thickness | 1-1/2", 1-1/4", 1-3/4", 1-3/8", 1-5/8", 1-7/8", 2", 2-1/2", 2-1/4", 2-1/8", 2-3/4", 2-3/8", 2-5/8", 2-7/8", 3" |
| Edge Bore | 1" |
| Handle Length | 5.3125 in. |
| Manufacturer Warranty | Limited Lifetime Mechanical |
| Collection | Rustic Sandcast Bronze |
| Series | Mariposa |
| Approved for Commercial Use | No |
| Country Of Origin | USA |
| ADA | No |
| Made in America | Yes |
| Fire Rated | No |
| Material | Bronze |
| Thermostat | Modern, Rustic |
| Concealed Screws | Yes |
| Function | Privacy |
| Handshower | Left, Reversible, Right |
| Handle Design | Mariposa |
| Handle Material | Metal |
| Rosette Shape | Arch, Rectangle, Round, Square |
| Latch Faceplate | Round Corner, Square Corner |
| Solid Construction | Solid Bronze |
| Locking Mechanism | Trim Lock |
| Lever Shape | Round, Straight |
| 28 Degree Latch | Yes |
| Color | Flat Black Bronze, Medium Bronze, Tumbled White Bronze |
| Color Tone | Bronze Tones |
