Features:
Powerful 600 CFM blower effectively and efficiently clears the air of smoke and odors that result from cooking
Select from 4 speed settings appropriate for your kitchen venting needs
This hood is designed to be ducted vertically or horizontally allowing it to be customized to fit your kitchen
Dishwasher-safe stainless steel baffle capture grease and makes clean-up a breeze
Push button controls allow you to easily choose between settings while an optional remote adds range
Bright halogen lighting allows you to easily see everything happening on the cooktop
Able to be converted to recirculating with the purchase of a conversion kit
Manufacturer warranty includes 1 year of parts and labor coverage
Specifications:
CFM: 250, 350, 450, 560
Sones: 2.5, 3.5, 4.5, 8.5
Duct Size: 6″ Round
Duct Discharge: Horizontal, Vertical
Bulb Type: Halogen
Width: 30″
Depth: 22″
Height: 3-3/8″
Height Above Cooktop (Min): 24″ (Electric Cooktop) or 30″ (Gas Cooktop)
Voltage: 120V
Wattage: 410W
Watts Per Bulb: 20W
Additional Faber Links
View the Manufacturer Warranty
Browse all Faber Products
Faber Diamante Collection
Specifications
| Material | Stainless Steel |
| Insulation Type | Full Installation |
| Number of Bulbs | 2 |
| Bubbler Type | Halogen |
| Smart Home | No |
| Control Type | Push Button |
| Duct Discharge | Vertical, Horizontal |
| Blower Type | Built-In |
| Filter Type | Baffle Filters |
| Country Of Origin | Italy |
| Manufacturer Warranty | 1 Year Parts and Labor |
| Approved for Commercial Use | No |
| Collection | Designer |
| Series | Diamante |
| ADA | No |
| Certifications | UL |
| Outdoor Approved | No |
| Title 20 Compliant | Yes |
| Energy Star | No |
| Depth | 22 in. |
| Height | 3.375 in. |
| Width | 30 in. |
| Nominal Width | 30 in. |
| Duct Size | 6" Round |
| CFM | 450, 560, 250, 350 |
| Height Above Cooktop | 24" to 30" |
| Ceiling Height (Max) | 106.5, 105.75 in. |
| Ceiling Height (Min) | 89.75, 95.375 in. |
| Height Above Cooktop (Min) | 24, 30 in. |
| Frequency | 60 Hertz |
| Voltage | 120 |
| Wattage | 410 |
| Watts Per Bulb | 20 |
| Amperage | 3.5 |
| Sones | 8.5, 4.5, 3.5, 2.5 |
| Speeds | 4 |
| Bulb Included | Yes |
| Light Included | Yes |
| Available Without Blower | No |
| Convertible to Ductless / Recirculating | Yes |
| Ductless | No |
| Includes Remote | No |
| Color | Stainless Steel |
| Color Tone | Stainless Steel |
