Features:
Includes a single hinge in each order
Precisely machined square corners
Removable pin for easy installation
Packaged with hinge, hinge pins, and mounting hardware
Constructed with eight screw holes in an arc arrangement
Tested for heavy duty residential applications
Covered by limited lifetime mechanical and 5 year finish warranties
Product Technologies:
Material – Solid Brass: Solid brass is prized for its resilience, durability, and beauty. It can always be polished back to its original sheen and is highly resistant to rusting. Solid brass is often available in finishes that other hinge materials are not.
Plain Bearing Hinge: Plain bearing hinges feature knuckles that are machined to a smooth surface, allowing them to move against one another without bearings. Plain bearing hinges are not recommended for heavy use on high traffic entrance ways, but meet the need of a standard residential door.
Mortise Hinge: Mortise door hinges mount flush with the surface of your door, providing maximum strength with the least interference with door functionality. It is recommended that three hinges be used on doors up to and including 7-1/2 feet, with one additional hinge for each additional 2-1/2 feet. Be sure to check your current hinges before making a purchase.
Specifications:
Height: 4.5″
Width: 4.5″
Material: Brass
Mounting Type: Mortise
Gauge (Thickness of Hinge): 0.1299″
Number of Knuckles: 5
Number of Holes: 8
Removable Pin: Yes
Product Variations:
BUTHNG-SQ-AR-HD-4: 4 x 4 Inch Door Hinge
BUTHNG-SQ-AR-HD-4.5 (This Model): 4.5 x 4.5 Inch Door Hinge
BUTHNG-SQ-MAR-RES-3.5: 3.5 x 3.5 Inch Door Hinge
BUTHNG-SQ-ST-RES-4: 4 x 4 Inch Door Hinge
Additional Grandeur Links
View the Manufacturer Warranty
Browse all Grandeur Products
Specifications
| Height | 4.5 in. |
| Width | 4.5 in. |
| Quantity | 1 |
| Gauge | 0.1299 |
| Corners | Square Corner |
| Hinge Size | 4-1/2 x 4-1/2 in. |
| Material | Brass |
| Thermostat | Traditional |
| Mounting Type | Mortise |
| Hinge Type | Plain Bearing |
| Hole Pattern | Arc |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | No |
| Approved for Commercial Use | No |
| ADA | No |
| Manufacturer Warranty | 5 Year Finish, Limited Lifetime Mechanical |
| Lead Leaching Certified NSF/ANSI 61 | N/A (Regulation does not apply) |
| Usage Level | Heavy Duty |
| Color | Antique Pewter, Bright Chrome, Polished Brass, Polished Nickel, Timeless Bronze, Unlacquered Brass, Vintage Brass, Satin Nickel |
| Color Tone | Brass Tones, Bronze Tones, Nickel Tones, Silver Tones |
