Features:
Includes a single hinge in each order
Precisely machined square corners
Removable pin for easy installation
Packaged with hinge, hinge pins, and mounting hardware
Constructed with six screw holes in an arc arrangement
Tested for heavy duty residential applications
Covered by limited lifetime mechanical and 5 year finish warranties
Product Technologies:
Material – Solid Brass: Solid brass is prized for its resilience, durability, and beauty. It can always be polished back to its original sheen and is highly resistant to rusting. Solid brass is often available in finishes that other hinge materials are not.
Plain Bearing Hinge: Plain bearing hinges feature knuckles that are machined to a smooth surface, allowing them to move against one another without bearings. Plain bearing hinges are not recommended for heavy use on high traffic entrance ways, but meet the need of a standard residential door.
Mortise Hinge: Mortise door hinges mount flush with the surface of your door, providing maximum strength with the least interference with door functionality. It is recommended that three hinges be used on doors up to and including 7-1/2 feet, with one additional hinge for each additional 2-1/2 feet. Be sure to check your current hinges before making a purchase.
Specifications:
Height: 4.5″
Width: 4.5″
Material: Brass
Mounting Type: Mortise
Gauge (Thickness of Hinge): 0.1299″
Number of Knuckles: 5
Number of Holes: 8
Removable Pin: Yes
Product Variations:
STEHNG-SQ-AR-HD-4: 4 x 4 Inch Door Hinge
STEHNG-SQ-AR-HD-4.5 (This Model): 4.5 x 4.5 Inch Door Hinge
STEHNG-SQ-MAR-RES-3.5: 3.5 x 3.5 Inch Door Hinge
STEHNG-SQ-ST-RES-4: 4 x 4 Inch Door Hinge
Additional Grandeur Links
View the Manufacturer Warranty
Browse all Grandeur Products
Specifications
| Approved for Commercial Use | No |
| ADA | No |
| Manufacturer Warranty | 5 Year Finish, Limited Lifetime Mechanical |
| Usage Level | Heavy Duty |
| Height | 4.5 in. |
| Width | 4.5 in. |
| Quantity | 1 |
| Corners | Square Corner |
| Gauge | 0.1299 |
| Hinge Size | 4-1/2 x 4-1/2 in. |
| Material | Brass |
| Thermostat | Traditional |
| Hinge Type | Plain Bearing |
| Hole Pattern | Zig Zag |
| Mounting Type | Mortise |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | No |
| Color | Antique Pewter, Bright Chrome, Polished Brass, Polished Nickel, Satin Nickel, Timeless Bronze, Unlacquered Brass, Vintage Brass |
| Color Tone | Brass Tones, Bronze Tones, Nickel Tones, Silver Tones |
