Grundfos 22 GPM SQE15220 3″ Multistage, Submersible Pump, 220 FT Rated Head, and Polyethylene / Stainless Steel Construction

22 SQE15220 3″ multistage, submersible pump designed for domestic water supply, liquid transfer in tanks, irrigation and environmental applications. The pump has “floating” impellers, each with its own tungsten carbide/ceramic bearing. The pump features soft starting and protection against dry running, up thrust, overvoltage, under voltage, overload and over temperature. The motor is a one phase motor of the permanent magnet rotor type ensuring optimum efficiency within a wide load range. The motor is fitted with a replaceable cable plug.

Technical:

Speed for pump data: 10700 rpm
Rated flow: 22 US gpm
Rated head: 220 ft
Approvals on nameplate: UL, cUL
Approvals on motor nameplate: CE,UL,CUL

Material:

Pump: Polyethylene / Stainless steel
Pump: DIN W.-Nr. 1.4301
Motor: Stainless steel
Motor: DIN W.-Nr. 1.4301
Motor: AISI 304

Installation:

Pump outlet: NPT 1 1/2
Minimum borehole diameter: 2.99 in

Liquid:

Maximum liquid temperature: 95 °F
Maximum liquid temperature at 0.15 m/sec: 95 °F

Electrical Data:

Motor type: MSE3
Power input – P1: 2.54 kW
Rated power – P2: 2.48 HP
Main frequency: 60 Hz
Rated voltage: 1 x 200-240 V
Start. method: Direct-on-line
Service factor: 1,65
Rated current: 12.3 A
Power factor: 1,00
Rated speed: 10700 rpm
