Product Features:
Ceramic shaft and radial bearings
Carbon axial bearing
Stainless steel rotor can and bearing plate
Corrosion-resistant impeller, Composite, PES
Stainless steel pump housing
The motor is a 1-phase motor
No additional motor protection is required
Product Specifications:
Liquid Temperature Range: 35 to 230 Degrees F
Approvals on Nameplate: UL, CSA
Pump Housing: Stainless Steel
Impeller: Composite, PES
Maximum Ambient Temperature: 104 Degrees F
Ambient Max at 176 Degrees F Liquid: 176 Degrees F
Maximum Operating Pressure: 145 PSI
Flange Standard: USA Oval
Type of Connection: Stainless Steel Flange
Pipe Connection: 2 Bolt Flange
Pressure Stage: 10
Port-to-Port Length: 6-1/2″
Number of Poles: 2
Maximum Power Input: 87 W
Rated Power – P2: 0.04 HP
Main Frequency: 60 Hz
Rated Voltage: 1 x 115 V
Current in Speed 3: 3/4 A
Capacitor Size – Run: 10 F/180 V
Additional Grundfos Links
Browse all Grundfos Products
Specifications
| Height | 5.5 in. |
| Product Weight | 6 lbs. |
| Length | 6.5 in. |
| Water Pressure (Max) | 145 PSI |
| Material | Stainless Steel |
| Impeller Material | Plastic |
| Housing Material | Stainless Steel |
| Certifications | UL, CSA |
| Low Lead Compliant | Yes |
| Voltage | 115 |
| Frequency | 60 Hertz |
| Horsepower | .121 |
| Electrical Phases | 1 |
| Maximum Fluid Temperature | 176 °F |
| Maximum Operating Pressure (PSI) | 145 |
