Features:
Sold individually
Features precisely machined square corners and decorative finials
Coordinates with Hafele’s Elite Series
Does not include installation screws, purchase #6 x 5/8″ screws separately
Constructed with six screw holds in a straight hole pattern
Hafele covers this product with a one year limited
Product Technologies:
Full Overlay: An overlay hinge is needed when the cabinet door you are mounting overlays the cabinet frame itself. Overlay hinges install on the interior edge of the cabinet frame and the interior face of the door, providing full motion with complete concealment of the hardware itself when the cabinet door is closed.
Material – Brass: Many door hardware products are crafted from aluminum or plated steel, but the difference between these lesser metals and heat forged brass is noticeable the minute you hold them in your hands—solid brass is heavier, smoother, and naturally resists corrosion, making it the ideal material to construct high quality, reliable door hardware.
Specifications:
Height: 1.9375″
Width: 1.625″
Material: Brass
Mount: Mortise
Gauge (Thickness of Hinge) : 0.0625″
5 Knuckles
6 Screw holes
Screws Included: No
Additional Hafele Links
View the Manufacturer Warranty
Browse all Hafele Products
Hafele Elite Collection
Specifications
| Adjustable Height | Yes |
| Insulation Type | Screw |
| Material | Brass |
| Soft Close | No |
| 3-Way Adjustable | No |
| Adjustable Depth | No |
| Adjustable Side to Side | Yes |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Demountable | No |
| Hinge Mount | Full Inset |
| Hinge Type | Butt |
| Number Of Hooks | 6 |
| Number of Knuckles | 5 |
| Self Closing | No |
| Approved for Commercial Use | No |
| Manufacturer Warranty | 1 Year Limited |
| Width | 1.9375 in. |
| Quantity | 1 |
| Length | 1.625 in. |
| Inset | Full |
| Color | Polished Brass |
| Color Tone | Brass Tones |
