Includes:
2 running gears
3 fixing cups and cover caps
2 suspension bolts and screws
1 door guide
1 alignment bracket
4 2mm spacers and 2 3mm spacers
Features:
Set for single door
Smooth, quiet operation
Left or right handed application
Upper track and lower guide channel not included
Installation plan included
Specifications:
Maximum door weight 88 lbs. (40 kg)
For door thickness 3/4″ to 1″ (19 – 25 mm)
Door up to 102.375″ (2600 mm) height and between 15.75″ – 35.5″ (400 – 900 mm) width
Height adjustable +/- 1/16″ (2 mm)
Depth adjustment up to 1″ (25 mm)
Additional Hafele Links
View the Manufacturer Warranty
Browse all Hafele Products
Hafele HAWA Aperto Collection
Specifications
Characteristics and Features
| Material | Steel, Synthetic |
| Number Of Doors | 1 |
Warranty and Product Information
| Approved for Commercial Use | No |
| Collection | HAWA Aperto |
Dimensions and Measurements
| Door Thickness | 1", 3/4", 7/8" |
| Max Door Weight | 88 lbs. |
| Max Door Width | 35.5 in. |
