Features:
Designed to support up to 100 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in panel (frameless) cabinets
Includes a 1 year limited manufacturer warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 26-1/2″
Slide Length: 26″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 100 lbs
Material: Steel
Cabinet Type: Panel
Quantity: 2
Product Variations:
422.16.311: 12 Inch Drawer Slide
422.97.950: 20 Inch Drawer Slide
422.04.650 (This Model): 26 Inch Drawer Slide
Additional Hafele Links
View the Manufacturer Warranty
Browse all Hafele Products
Hafele Accuride Collection
Specifications
| Extension | 26 in. |
| Length | 26 in. |
| Nominal Length | 26 in. |
| Max Capacity (Pounds) | 100 lbs. |
| Quantity | 2 |
| Drainboard Length | 26.5 in. |
| Minimum Cabinet Depth | 26.125 in. |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Adjustable | No |
| Extension Type | Full Extension |
| Soft Close | No |
| Cabinet Type | Panel (Frameless) |
| Self Closing | No |
| Detent | Yes |
| Disconnect Style | Lever |
| Push to Open | No |
| Slide Type | Ball Bearing |
| Collection | Accuride |
| Approved for Commercial Use | No |
| Manufacturer Warranty | 1 Year Limited |
| Series | Accuride |
| BHMA Certification | Grade 1 |
| Color | Zinc |
| Color Tone | Greys |
