Features:
Sold as a single hinge
Tested for commercial applications, ideal for medium weight use and low frequency services
Non-rising removable pin allows you to easily remove your door without uninstall the hinge
Includes eight (8) wood and machine screws
Constructed with eight (8) screw holes in an arc hole pattern for mounting strength
Hager offers a Limited Lifetime Warranty
Product Technologies:
Ball Bearing Hinge: Ball bearing hinges are designed to handle the extra stress brought on by high traffic doorways. The greased bearings reduce the rotational friction extending the life of a hinge in heavy use situations. These hinges tend to be more durable than standard, or plain bearing hinges.
Material – Steel: Steel is cheap, strong, and durable, making it a favorite for hinges of all types, despite it being slightly more prone to rusting than solid brass or stainless steel.
Mounting: The standard corners for mortised door hinges are 1/4″ radius, 5/8″ radius and square corner. It is recommended that three hinges be used on doors up to and including 7.5 feet with one additional hinge for each additional 2.5 feet. Make sure you check your current hinges before making a purchase.
Specifications:
Height: 4-1/2″
Width: 4″
Material: Stainless Steel
Mount Type: Mortise
Gauge (Thickness of Hinge Steel): 0.134″
Number of Knuckles: 5
Number of Holes: 8
Quantity: 1
Additional Hager Links
View the Manufacturer Warranty
Browse all Hager Products
Specifications
| Height | 4.5 in. |
| Width | 4 in. |
| Quantity | 1 |
| Gauge | 0.134 |
| Hinge Height | 4.5 in. |
| Hinge Size | 4-1/2 x 4 in. |
| Hinge Width | 4 in. |
| Installation Hardware Included | Yes |
| Material | Stainless Steel |
| Mounting Type | Mortise |
| Hinge Type | Ball Bearing |
| Hole Pattern | Arc |
| Number Of Hooks | 8 |
| Number of Knuckles | 5 |
| Removable Pin | Yes |
| Sconce Type | Wood, Machine |
| Approved for Commercial Use | Yes |
| Collection | Commercial |
| Manufacturer Warranty | Limited Lifetime |
| Certifications | ANSI |
| ANSI Certification | A5112 |
| Usage Level | Commercial Grade |
| Color | Satin Nickel |
| Color Tone | Nickel Tones |
