Features:
Drawer slides are rated for 100 pounds at full extension
Mounts to the side of the drawer for stability and strength
Provides easy access to drawer with full extension slides
Lever disconnect allows easy and quick removal of the drawer from the cabinet members
Designed to be installed in either panel or face frame cabinets
All Hardware Resources cabinet hardware comes with a limited lifetime warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
Drawer Length: 18″
Slide Length: 18:
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 100 lbs
Minimum Cabinet Depth: 18″
Material: Steel
Quantity: 30
Quantity: 30
Product Variations:
303-100-14C: 14 Inch Drawer Slide
303-100-16C: 16 Inch Drawer Slide
303-100-18C (This Model): 18 Inch Drawer Slide
Additional Hardware Resources Links
View the Manufacturer Warranty
Browse all Hardware Resources Products
Hardware Resources 303FU Collection
Specifications
| Material | Steel |
| Mounting Type | Side Mount |
| Adjustable | Yes |
| Extension Type | Full Extension |
| Soft Close | No |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Detent | Yes |
| Disconnect Style | Lever |
| Push to Open | No |
| Self Closing | No |
| Slide Type | Ball Bearing |
| Length | 18 in. |
| Quantity | 30 |
| Max Capacity (Pounds) | 100 lbs. |
| Drainboard Length | 18 in. |
| Minimum Cabinet Depth | 18 in. |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | No |
| Series | 303FU |
| BHMA Certification | Grade 1 |
| Color | Zinc |
| Color Tone | Greys |
