Features:
Designed to support up to 65 pounds of weight
Mounts to the side of the drawer
Less than full extension: 7.8″
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 10-1/2″
Slide Length: 10″
Extension Type: Less than full extension (7.8″)
Slide Type: Ball Bearing
Weight Capacity: 65 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
4450B 10 (This Model): 10 Inch Drawer Slide
4450B 12: 12 Inch Drawer Slide
4450B 14: 14 Inch Drawer Slide
4450B 16: 16 Inch Drawer Slide
4450B 18: 18 Inch Drawer Slide
4450B 20: 20 Inch Drawer Slide
4450B 22: 22 Inch Drawer Slide
4450B 24: 24 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 4450 Collection
Specifications
| Height | 1.42 in. |
| Width | 0.5 in. |
| Length | 10 in. |
| Nominal Length | 10 in. |
| Quantity | 2 |
| Extension | 10 in. |
| Max Capacity (Pounds) | 65 lbs. |
| Height mm | 36 mm |
| Width mm | 13 mm |
| Drainboard Length | 10.5 in. |
| Minimum Cabinet Depth | 10 in. |
| Minimum Clearance | 0.5 in. |
| Maximum Drawer Width | 24 in. |
| Collection | 4450 |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | Yes |
| Series | 4450 |
| BHMA Certification | Grade 1 |
| Material | Steel |
| Insulation Type | Side Mount |
| Adjustable | No |
| Soft Close | Yes |
| Mounting Type | Side Mount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Detent | Yes |
| Disconnect Style | Lever |
| Push to Open | No |
| Self Closing | No |
| Slide Type | Ball Bearing |
| Color | Zinc |
