Features:
Designed to support up to 130 pounds of weight
Concealed undermount construction adds stability and support
Provides maximum access to the drawer with overtravel slides
Rail disconnect allows easy removal of drawer
Slides can be installed in panel (frameless) cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 18-1/2″
Slide Length: 18″
Extension: Type: Over Travel
Slide Type: Concealed
Weight Capacity: 130 lbs
Material: Steel
Cabinet Type: Panel
Quantity: 2
Mounting hardware not included
Product Variations:
8000P 16: 16 Inch Drawer Slide
8000P 18 (This Model): 18 Inch Drawer Slide
8000P 20: 20 Inch Drawer Slide
8000P 22: 22 Inch Drawer Slide
8600P 24: 24 Inch Drawer Slide
8000P 26: 26 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8000 Collection
Specifications
| Height | 1.54 in. |
| Max Capacity (Pounds) | 130 lbs. |
| Width | 2.25 in. |
| Length | 18 in. |
| Quantity | 2 |
| Nominal Length | 18 in. |
| Height mm | 39 mm |
| Width mm | 57 mm |
| Minimum Clearance | 2.25 in. |
| Drainboard Length | 18.5 in. |
| Minimum Cabinet Depth | 18 in. |
| Adjustable | No |
| Insulation Type | Bottom Mount |
| Material | Steel |
| Extension Type | Over Travel |
| Soft Close | No |
| Mounting Type | Concealed Undermount |
| Cabinet Type | Panel (Frameless) |
| Self Closing | No |
| Detent | Yes |
| Disconnect Style | Rail |
| Push to Open | No |
| Slide Type | Concealed |
| Approved for Commercial Use | Yes, No |
| Collection | 8000 |
| Manufacturer Warranty | Limited Lifetime |
| Series | 8000 |
| BHMA Certification | Grade 1 |
| Color | Anochrome |
| Color Tone | Silver Tones |
