Features:
Designed to support up to 90 pounds of weight
Mounts to the side of the drawer
Provides maximum access to the drawer with overtravel slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Self Closing: Gently push on the door front to engage the integrated spring mechanism. Once activated, these slides will close the drawer for you in one smooth movement.
Soft Close: Whether large or small, heavy or light, soft closing action keeps drawers from slamming closed. It adapts to various closing speeds and features overload safety to protect the system from damage over time.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 18-1/2″
Slide Length: 18″
Extension: Type: Over Travel
Slide Type: Ball Bearing
Weight Capacity: 90 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
8455FMB 16: 16 Inch Drawer Slide
8455FMB 18 (This Model): 18 Inch Drawer Slide
8455FMB 20: 20 Inch Drawer Slide
8455FMB 22: 22 Inch Drawer Slide
8455FMB 24: 24 Inch Drawer Slide
8455FMB 28: 28 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8455FM Collection
Specifications
| Height | 1.79 in. |
| Width | 0.5 in. |
| Quantity | 2 |
| Length | 18 in. |
| Width mm | 13 mm |
| Nominal Length | 18 in. |
| Max Capacity (Pounds) | 90 lbs. |
| Height mm | 46 mm |
| Drainboard Length | 18.5 in. |
| Maximum Drawer Width | 24 in. |
| Minimum Cabinet Depth | 18 in. |
| Minimum Clearance | 0.5 in. |
| Adjustable | No |
| Material | Steel |
| Insulation Type | Side Mount |
| Mounting Type | Side Mount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Extension Type | Over Travel |
| Soft Close | Yes |
| Self Closing | Yes |
| Detent | No |
| Disconnect Style | Lever |
| Push to Open | No |
| Slide Type | Ball Bearing |
| Collection | 8455FM |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | Yes, No |
| Series | 8455FM |
| BHMA Certification | Grade 1 |
| Color | Anochrome |
