Features:
Designed to support up to 150 pounds of weight
Mounts to the side of the drawer
Provides easy access to the drawer with full extension slides
Lever disconnect allows easy removal of entire drawer system
Slides can be installed in either panel (frameless) or face frame cabinets
Includes a limited lifetime manufacturer warranty
Product Technologies:
Detent: Also known as anti-rebound, slide detent acts like a brake; ensuring your drawers do not roll back open when closed with too much force.
Specifications:
BHMA Certification: Grade 1
Recommended Drawer Length: 20-1/2″
Slide Length: 20″
Extension Type: Full Extension
Slide Type: Ball Bearing
Weight Capacity: 150 lbs
Material: Steel
Cabinet Type: Face Frame, Panel
Quantity: 2
Mounting hardware not included
Product Variations:
8500B 18: 18 Inch Drawer Slide
8500B 20 (This Model): 20 Inch Drawer Slide
8500B 22: 22 Inch Drawer Slide
Additional Knape and Vogt Links
Browse all Knape and Vogt Products
Knape and Vogt 8500 Collection
Specifications
| Height | 3.79 in. |
| Width | 0.5 in. |
| Length | 20 in. |
| Nominal Length | 20 in. |
| Quantity | 2 |
| Extension | 20 in. |
| Max Capacity (Pounds) | 150 lbs. |
| Height mm | 96 mm |
| Width mm | 13 mm |
| Drainboard Length | 20.5 in. |
| Minimum Cabinet Depth | 20 in. |
| Minimum Clearance | 0.5 in. |
| Maximum Drawer Width | 36 in. |
| Collection | 8500 |
| Manufacturer Warranty | Limited Lifetime |
| Approved for Commercial Use | Yes, No |
| Series | 8500 |
| BHMA Certification | Grade 1 |
| Material | Steel |
| Insulation Type | Side Mount |
| Adjustable | No |
| Extension Type | Full Extension |
| Soft Close | No |
| Mounting Type | Side Mount |
| Cabinet Type | Face Frame, Panel (Frameless) |
| Detent | Yes |
| Disconnect Style | Lever |
| Push to Open | No |
| Self Closing | No |
| Slide Type | Ball Bearing |
| Color | Anochrome |
